API Decanter centrifuge
- 20 Set / Sets per Month
- Shanghai Tianjin
- T/T
You May Like
-
Electric Drilling fluid mixer/hoppers for 1500m-9000m drilling rig
-
180 m3/ h Drilling fluid mixer/hoppers for 1500m-9000m drilling rig
-
200 m3/ h Drilling fluid mixer/hoppers for 1500m-9000m drilling rig
-
240 m3/ h Drilling fluid mixer/hoppers for 1500m-9000m drilling rig
-
30 KW drilling mud centrifuge pump
-
150 GPM drilling mud centrifuge pump
Product Details
| Place of Origin | China | Brand Name | Sinotai | |
| Model Number | LWF450*842N | Voltage | 380V | |
| Power(W) | 22000 | Weight | 2550kg | |
| Dimension(L*W*H) | 2360*1850*1750mm | Warranty | 12 months | |
| Condition | New | Certification | api |
Standard Package
Product Description
Specifications
fluids decanter centrifugeLow energy consumption ,Low noise,High efficient, large capacity
automatic continuous operation
Centrifuge
Main feature:
LW centrifuge is driven by two motors.
The main motor drives the drum and the outer casing of differential through belts while the auxiliary motor, after the differential shifting speed, drives the spiral propeller.
This will make the drum and the spiral propeller rotate inthe same direction with a certain differential speed.
Technical Parameters:
Model | LWF450×842N | LWF450×1000N | GLW355×1250N | GLW355x1250 |
Bowl Diameter | 450mm | 450mm | 355mm | 355mm |
Rotary Speed | 1800r/min | 1800r/min | 3200r/min | 0~3200r/min |
G-Force | 815 | 815 | 2035 | 2035 |
Separation point | 5~7μm | 5~7μm | 2~5μm | 2~5μm |
Main Drive | 22kw-4p | 30kw-4p | 30kw-4p | 37kw-4p |
Back Drive | 5.5kw-4p | 7.5kw-4p | 7.5kw-4p | 7.5kw-4p |
Max capacity | ≤40m3/h | ≤60m3/h | ≤40m3/h | ≤40m3/h |
Weight | 2550kg | 2700kg | 2950kg | 3000kg |
Dimension | 2360x1850x1750mm | 2600x1860x1750mm | 2900x1850x1750mm | 2900x1950x1750mm |
