Home > Products > solid control system > API Centrifuge
API Centrifuge
- Tianjin new port Qingdao Shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Centrifuge | |
| Place of Origin | Shandong, China | Brand Name | Sinotai | |
| Model Number | LW | Power(W) | 22kw | |
| Weight | 2550~3000kg | Dimension(L*W*H) | 2360x1850x1750mm | |
| Certification | API | Warranty | 18 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
wooden or iron box/ according to your requirements
Product Description
Specifications
1. LW centrifuge2.drives the drum and the outer casing
3. recycling barite
Specifications
1.High quality of screw propeller and bearings
2.Small vibration and low noise
3.Equipped with VVVF, low energy consumption
Centrifuge
Main feature:
1. LW centrifuge is driven by two motors.
2. The main motor drives the drum and the outer casing of differential through belts while the auxiliary motor, after the differential shifting speed, drives the spiral propeller.
3. This will make the drum and the spiral propeller rotate in the same direction with a certain differential speed.
4. Mainly used for recycling barite to remove small solid, reduce drilling fluid solid content, control the density of drilling fluid viscosity, to ensure that the drilling fluid performance and an important role for fast drilling
Technical Parameters:
Model | LWF450×842N | LWF450×1000N | GLW355×1250N | GLW355x1250 |
Bowl Diameter | 450mm | 450mm | 355mm | 355mm |
Rotary Speed | 1800r/min | 1800r/min | 3200r/min | 0~3200r/min |
G-Force | 815 | 815 | 2035 | 2035 |
Separation point | 5~7μm | 5~7μm | 2~5μm | 2~5μm |
Main Drive | 22kw-4p | 30kw-4p | 30kw-4p | 37kw-4p |
Back Drive | 5.5kw-4p | 7.5kw-4p | 7.5kw-4p | 7.5kw-4p |
Max capacity | ≤40m3/h | ≤60m3/h | ≤40m3/h | ≤40m3/h |
Weight | 2550kg | 2700kg | 2950kg | 3000kg |
Dimension | 2360x1850x1750mm | 2600x1860x1750mm | 2900x1850x1750mm | 2900x1950x1750mm |
Company Profile
As a professional supplier of OCTG, drilling equipment and workover service, Sinotai Petroleum Equipment Co., Ltd. lies in the production base of petroleum equipment and China's second largest oil field --Shengi Oilfield. Our company is a high-tech enterprise in Dongying City with business scope covering the sale, trading, post-sale service and technological development of a wide variety of petroleum equipment. Besides OCTG, we provide our customers with other drilling and oil recovery equipment like fishing tools, cementing tools, workover rigs, pumping units and OCTG accessories. The striving target of our company is "Prestige first, Quality supreme; The shortest delivery time, The lowest price, The best quality". Customers' needs are our first priority and customer satisfaction is the bottom line by which we measure our success.
