Product Details
| Place of Origin | Zhejiang, China | Brand Name | Chenf | |
| Model Number | CF-300Y | Output Power | Other, 300W | |
| Output Type | Single | Size | 200*105*60 | |
| Weight | 1.13KG | Input Voltage | 12V/24V/48V/110V | |
| Output Voltage | 100/110/120VAC or 220/230/240 VAC | Type | DC/AC Inverters | |
| Output Frequency | 50/60Hz |
Product Description
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
Specifications
1.Dc to ac pure sine wave inverter
2.High surge capability
3.Inbuilt super charge
4.Inbuit transformer
5.High Transform efficiency
6.CE/SONCAP
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
Features
*Peak power is three times of rated power.
*Can work with inductive load such as air conditioner, motor door and so on.
*Pure sine wave output, available for sensitive load.
*4-step progressive charging, 7 battery type selector.
*Fast and powerful charger with 35A and 70A.
*Accept generator’s energy output.
*High power factor 0.9, low power consumption.
*Automatically transfer between battery and line modes.
*Microprocessor control guarantees high reliability.
*Bypass without battery connected.
*Remote control function.
*Protection against: Over load, over temperature, over charging, low battery
*Reverse connection (optional by hard connector), Blackouts
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
Applicable For
1.Travel set equipment:military vehicles,police cars,ambulances,ships,traffic lights,etc.
2.Industrial equipment:solar energy,wind power,gas discharagelamps,etc.
3.Office equipment:computers,printers,copiers,scanners,digital cameras,etc.
4.Kitchen equipment:microwave,oven battery,refrigerators,etc.
5.Household electrical equipment:electric fans,vacuum cleaners,air conditioning,lighting,tv,washing machine,etc.
6.Power tools:saws,drilling machines,punching machines,air compressors,etc.
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
Product Image
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
Data
Size: 200cm*150cm*60cm
Weight:1.13KG
Working temperature: -10-50degree
Storage temperature: -30-70degree
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
Parameters
| Model | CF-300Y | ||||
| Input | DC voltage | 12V | 24V | 48V | 110V |
| Voltage range | 10-16VDC | 20-33VDC | 40-63VDC | 90-130VDC | |
| No load current draw | 0.7A | 0.4A | 0.2A | 0.1A | |
| Efficiency | >90% | ||||
| DC connection | Cables With Clips or Car Adaptor | ||||
| Output | AC voltage | 100/110/120VAC or 220/230/240 VAC | |||
| Continuous power | 300W | ||||
| Surge power | 600W | ||||
| Waveform | Pure sine wave | ||||
| Frequency | 50Hz or 60Hz | ||||
| AC regulation | 3% | ||||
| Protection | Low voltage alarm | 10.5DC±0.5V | 21DC±1V | 42VDC±1V | 96VDC±3V |
| Low voltage shut down | 10DC±0.5V | 20DC±1V | 40VDC±1V | 90VDC±3V | |
| Short circuit | Shut off output automatically | ||||
| Over load | Shut off output | ||||
| Over voltage shut down | 16±0.5V | 33±1V | 63±1V | 130±3V | |
| Over thermal | Shut off output automatically | ||||
| Environment | Working temperature | between -10°C and +50°C | |||
| Working humidity | 20%~90%RH | ||||
| Storage temperature | between -30°C and +70°C | ||||
| Package | Machine size(mm) | 200*105*60 | |||
| Packing size(mm) | 275*160*113 | ||||
| Net weight(kg) | 0.86 | ||||
| Gross weight(kg) | 1.13 | ||||
| Packing mode | Carton packaging | ||||
| Other | Start | Soft start | |||
| Cooling ways | Intelligent cooling fan | ||||
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
Payment
1.We accept T/T, Paypal, Western Union, Alibaba Escrow, and others. You can choose the one you like. If you want other payment terms please let us know before your order.
2.If pay online, make sure that you have completed all the detailed information like contract person, address, post code, telephone number.
Package Content
Shipping
DHL,UPS,FedEx,EMS,TNT,Air,Sea
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
CE Certification
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
We are real factory.8 years export experience.
We will send the goods out within 72 hours after the order confirmed.
12 months warranty,any question will be answered in 12 hours.
If the pruduct really has quality problem,we will accept return the old and send a new.
Chenf Electric Group Limited. (called "Chenf" for short) is a wholly owned subsidiary of Chenf Electrical Group Limited. Founded in 2008, we are a modern enterprise specialized in offering one-stop service to customers.
- Chenf concentrates on the design, production and sales of renewable energy product, hi-voltage product, low-voltage product, pneumatic actuator, etc
- Chenf will continue to take "create value for customers.
Enterprise Vision: To create electrical products airline carrier.
Newest Design Micro Control Home Use Small Rechargeable Dc To Ac Converter Circuit Diagram Power Inverter Price 300w
Q1.What is the MOQ?
A1.10 pieces.
Q2.Could I buy a sample befor place the order.
A2.Yes,It is ok. Welcome your samples order.
Q3.What is way of Payment?
A3.L/C,T/T.Wester Union,Paypal(Just choose which one is best for you)
Q4.The model of transportation
A4.FOB Ningbo or Shanghai
Q5.What is the best price?
A5.Give me a inquiry or chat with me online,please.Then I will give you best answer.
