Multi Colors T-shirt Shopping Bag Flexographic Printing Press

Usage:

This T-shirt shopping bag flexographic printing press adopts photosensitive resin as printing plate, is commonly known as the flexographic printing machine. It is suitable for printing packing materials such as polyethylene (PE), polypropylene (PP) bag, nylon, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

Colors:

Material:

Plastic film in roll, paper in roll, non-woven in roll, ect.

Model

YT-6600

YT-6800

YT-61000

YT-61200

Material

Plastic film rolls, paper rolls, non-woven rolls etc.

Material feeding width

600mm

800mm

1000mm

1200mm

Max printing width

560mm

760mm

960mm

1160mm

Printing length

180-960mm

Printing speed

5-50m/min

Mechanical speed

60m/min

Printing plate lifting method

Manual/pneumatic/hydraulic

Plate thickness

2.38mm

Anilox cylinder

Metal

Printing cylinder with machine

100-400mm one set

Register precision

±0.35mm

Max rewind and unwind diameter

450mm

Power of main motor

3.5kw

3.5kw

4kw

4kw

Heating power

10kw

10kw

12kw

12kw

Blower of heating

0.75kw and 0.55kw

Inking motor

0.55kw

Machine weight

3500kg

3800kg

4200kg

4500kg

Machine dimension(L)*(W)*(H)

4.8*1.7*2.5m

4.8m*1.9*2.5m

4.8*2.1*2.5m

4.8*2.3*2.5m

Voltage of machine

380V, 3phase, 50Hz

Features of T-shirt shopping bag flexographic printing press

1.Easy operation, flexible starting, and accurate color register.

2.The meter counter can set printing quantity according to the requirements. Stop the machine

automatically at the set quantity or when the material is cut off.

3.Lift and lower the printing plate cylinder manually, it will automatically stir the printing ink after lifting.

4.The printing ink is spread by the knurled cylinder with even ink color.

5.Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.

6.360° continuous and adjustable longitudinal register devices.

7.The imported frequency control of motor speed adapts to different printing speeds.

8.There are inching/stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

Free spare parts T-shirt shopping bag flexographic printing press

No.

Name

Quantity

1

Tool Box

1 set

2

1-10# screwdriver

1 pcs

3

oil gun

1 pcs

4

Inner Hexagon Spanner

1 set

5

Switches

2 pcs

6

Contactor

2 pcs

7

heating tube

2 pcs

8

Machine operation instruction

1 pcs

In order to quote you exact printing machine, please offer us following details:

1-How many colors do you want?

2-What is the printing width you need?

3-Please send me photos of the logo you will print?
