Home > Products > Ship building steel plate > Wuhan Steel Plates for Marine, Ship Breaking Plate
Wuhan Steel Plates for Marine, Ship Breaking Plate
- Main port in China
- T/T
You May Like
-
Marine Steel Sheet Ship Builder Steel Plate
-
Trade Assurance Supplier Ship Plate for Sale
-
Grade A B D E Normal Strength Shipbuilding Steel Plate Trade Assurance Supplier
-
Trade Assurance Supplier of Marine Steel Plate
-
AH36,DH36,EH36 Ship Plate Mild Steel Plate for Shipbuilding
-
Trade Assurance Supplier of AH32 Shipbuilding Steel Plates Hot Rolled Ship Plate
Product Details
| Standard | AISI, ASTM, BS, DIN, GB, JIS | Grade | High strength structural steel | |
| Thickness | 6-38mm | Place of Origin | Hubei, China | |
| Brand Name | STECH | Model Number | 6-38mm*1800-3200mm*7000-12000mm | |
| Type | Steel Plate | Technique | Hot Rolled | |
| Surface Treatment | Coated | Application | Ship Plate | |
| Special Use | High-strength Steel Plate | Width | 1800-3200mm | |
| Length | 7000-12000mm |
Product Description
Wuhan steel plates for marine, ship breaking plate
The ship building steel (Hull structural steel) is divided to normal strength and high strength structural steel according to strength grade. Ship plate is a kind of hot rolled steel plate and produced for making hull structure according to the constructions rules of the Classification Society. The normal strength structural steel has four quality grades as A,B,D,E according to the classification society standard rules and the high strength structural steel has three strength grades and four quality grades.
The ship plate has been widely used in ship building, construction, light industry, household appliance, automobile, ocean projects, boatyard, dock facilities, etc.
1. The main Classification Society
China CCS
USA ABS
German GL
France BV
Norway DNV
Japan NK
England LR
Korea KR
Italia RINA
2. Main Steel Grade
| Classification Society | Application | Steel Grade |
| CCS | normal strength | CCS-A,CCS-B,CCS-D,CCS-E |
| high strength | CCS-A32,CCS-A36 | |
| DNV | normal strength | DVA,DVB,DVD,DVE |
| high strength | DV A32, DV A36 | |
| GL | normal strength | GL-A,GL-B,GL-D,GL-E |
| high strength | GL-A32, GL-A36 | |
| ABS | normal strength | AB/A,AB/B,AB/D,AB/E |
| high strength | AB/AH32,AH36 | |
| LR | normal strength | A,B,D,E |
| BV | high strength | AH32,AH36 |
3. Standard
AISI, ASTM, BS, DIN, GB, JIS
4. Available Size
Thickness: 3~38mm
Width: 1219~3200mm
Length: 2500~12000mm
or as per customer's request
5. Brands
WISCO, Baosteel, Xinyu Steel, Jinan Steel, An Steel, Rizhao Steel, POSCO etc...
6. Mechanical Properties
| Grade | Thickness (mm) | Yield point (Mpa) | Tensile Strength (Mpa) | Elongation (%)≤ | Impact test | Cold Bend Test | |||
Temperature (0C) | Average AKVA KV/j | b=2a 1800 | b=5a 1200 | ||||||
| lengthways | crosswise | ||||||||
| ≥ | |||||||||
| A | ≤50 | 235 | 400~490 | 22 | / | / | / | d=2a | / |
| B | 0 | 27 | 20 | / | d=3a | ||||
| D | -10 | ||||||||
| E | -40 | ||||||||
| AH32 | ≤50 | 315 | 440~590 | 22 | 0 | 31 | 22 | / | d=3a |
| DH32 | -20 | ||||||||
| EH32 | -40 | ||||||||
| AH36 | ≤50 | 355 | 490~620 | 21 | 0 | 34 | 24 | / | d=3a |
| DH36 | -20 | ||||||||
| EH36 | -40 | ||||||||
- Carbon structural steel
- High strength structural steel
- Wear Resistance/Abrasion-Resistant steel plate
- Pressure vessel plate/boiler steel plate
- Weathering steel/Corten steel
