Home Security Mobile Remote Camera 720P HD Mini Wifi IP Camera P2P Baby Monitor

Mini IP Camera P2P IR Cut WiFi Wireless Network IP Security Camera Webcam H.264 1.0MP HD 720P

Highlight:

Plug &Play (P2P), No need DDNS, No need Port Forwarding.

setting no need PC. You can easily realize all the function via the APP

Remote view by Mobile device including Android, iPhone, iPad and PC (CMS & Browser)

Main Features:

support Wifi

support TF card. up to 32G(not include)

support two way audio(Built-in MIC and speakers)

support P2P. view & anywhere & anytime

3.6mm fixed lens

10pcs infrared LEDs. 10m Night Vision

elegant outline and easy installation

provide android & ios APP

Specifications

Camera:

• Operating system: Embedded Linux OS
• Processor: HI3518E
• Sensor: 1/4" OV9712 CMOS Digital Image Sensor
• Lens interface type: M12
• Lens:3.6mm F2.0 Fixed lens
• View angle: 62.2°
• Min.illumination: 0.1 Lux  / 0 Lux(IR on)
• Day&Night mode: Auto IR-CUT
• Night vision distance: 10pcs 850nmΦ5mm IR LEDs. IR irradiation distance 10m

Video

• Video compression standard: H.264
• Video streaming: Three streaming
• Video resolution
• First stream:720P(1280x720)
• Second stream:Q720P(640x480)
• Third stream:QQ720P(320x180)
• Video code rate: 32~4096Kbps. rate adaptive
• Video frame rate:25fps
• Image settings:Brightness, contrast,saturation,exposure,Hue
• Image enhancement:Backlight compensation,Automatic white balance,Digital WDR, 3D digital noise reduction

Audio:

• Audio compression standard:AAC
• Audio code rate:Rate adaptive

Function:

• Motion detecting:Support
• Alarm linkage:Alarm send pictures to the specified mailbox; alarm image and record write Micro SD card; buzzer alarm; message push
• OSD:Support camera name. date and time information superimposed
• Simultaneous viewers:maximum support 12 users to simultaneously browse (each stream supports 4 users)
• Network protocol:TCP/IP,HTTP,TCP,ICMP,UDP,ARP. IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP
• Connection protocol:Support ONVIF 2.0(backward compatible)

Wireless:

• Wireless standards:IEEE802.11b; 802.11g; 802.11n Draft
• Frequency range:2.4 GHz ~ 2.4835 GHz
• Wireless Security:64/128-bit WEP; WPA/WPA2; WPA-PSK/WPA2-PSK; WPS
• Transmission rate:11b: 11Mbps; 11g :54Mbps; 11n :135Mbps

Interface

• Power interface: 1 Micro usb power interface
• Ethernet:1 RJ45 & Antenna 10M/100M Adaptive Ethernet Interface
• TF card Slot: 1 TF card slot, up to 32G
• Reset button: support

General specification

• Power supply: DC 5V 2A
• Power: Day:<3W. Night:<8W
• Operating temperature: -20℃~+60℃
• Operating humidity: 10%~90%
• Installation: Rack/ceil mounting

Accessories:

1* Power supply;

1bag*Screws;

1*antenna;

1*manual
