Cpu Fan With Big Airflow 70 x 70 x 25mm
US$ 1 - 8
/ Piece
500 Pieces(Min. Order)
- SZ
- T/T
You May Like
Product Details
| Electric Current Type | DC | Mounting | Other, Built-in cooling fan | |
| Blade Material | Plastic | Place of Origin | Guangdong, China | |
| Brand Name | topfan | Model Number | YM2407PTS(B)1 | |
| Voltage | 24V | Power | 3.36W | |
| Air Volume | 43.59CFM | Speed | 4000rpm | |
| Certification | CCC, CE, ROHS, UL, CE, Other, UL, CCC, CE, ROHS, UL, CE, ISO9000, UL, TUV, RoHS |
Product Description
Discription of RoHS approved ac fan 70 x 70 x 25mm
1. Expexted life
1). Ball Bearing 50,000 hours(400C)
2). Sleeve Bearing 30,000 hours(400C)
2. Allowable Ambient Temperature Range:
1). -100C~+700C (Operating)
2). -400C~+700C (Storage)
3). non-condensing environment
General Specification
| Model | YM2407PTS(B)1 |
| Frame | Plastic(UL94V-0) |
| Impeller | Plastic(UL94V-0) |
| Bearing Ball | Sleeve Bearing & Bual Ball Bearing |
| Leadwire | UL1007AWG24 or Equivalent (+): Red (-0 Black |
| Motor | Impedance Protected and Reverse Polarity Protected |
Product Features
| Size(mm) | Model | Rated voltage (v) | Operating Voltage Range(v) | Current amp (Amp) | Rated Input Power Watt | Speed (rpm) | Max air Flow(CFM) | Max Static Pressure (Inch-H2o) | Noise Leve (dB-A) | Weight (g) |
| 70*70 *25 | YM2407PTS(B)1 | 24 | 14.0 to 27.6 | 0.14 | 3.36 | 4000 | 43.6 | 0.2 | 37 | 52 |
Our Series of 70 X 70 X 25mm
| Size(mm) | Model | Rated voltage (v) | Operating Voltage Range(v) | Current amp (Amp) | Rated Input Power Watt | Speed (rpm) | Max air Flow(CFM) | Max Static Pressure (Inch-H2o) | Noise Leve (dB-A) | Weight (g) |
| 70*70 *25 | YM1207PTS(B)1 | 12 | 7.0 to 13.8 | 0.19 | 2.28 | 4000 | 43.6 | 0.2 | 37 | 52 |
| YM1207PTS(B)2 | 12 | 7.0 to 13.8 | 0.16 | 1.92 | 3500 | 38 | 0.17 | 32 | 52 | |
| YM1207PTS(B)3 | 12 | 7.0 to 13.8 | 0.13 | 1.56 | 3000 | 32.4 | 0.15 | 28 | 52 | |
| YM2407PTS(B)1 | 24 | 14.0 to 27.6 | 0.14 | 3.36 | 4000 | 43.6 | 0.2 | 37 | 52 | |
| YM2407PTS(B)2 | 24 | 14.0 to 27.6 | 0.11 | 2.64 | 3500 | 38 | 0.17 | 32 | 52 | |
| YM2407PTS(B)3 | 24 | 14.0 to 27.6 | 0.08 | 1.92 | 3000 | 32.4 | 0.15 | 28 | 52 | |
| YM4807PTS(B)1 | 48 | 28.0 to 56.0 | 0.08 | 3.84 | 4000 | 43.6 | 0.2 | 37 | 52 | |
| YM4807PTS(B)2 | 48 | 28.0 to 56.0 | 0.06 | 2.88 | 3500 | 38 | 0.17 | 32 | 52 | |
| YM4807PTS(B)3 | 48 | 28.0 to 56.0 | 0.05 | 2.4 | 3000 | 32.4 | 0.15 | 28 | 52 |
