QA34 -16 Mechanical Ironworker , Ironworker Machine
US$ 3,000 - 6,000
/ Set
1 Set(Min. Order)
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
J23 Series Open-type Tilting Power Press
-
J23 Series Open-type Tilting Power Press
-
J23 Series Open-type Tilting Power Press
-
Mechanical Power Press J21,J23,JH21 Series Press Machine / Punching Machine
-
High Quality Hydraulic Sheet Metal Cutting Machine , Hydraulic Shearing Machine Price
-
China Manufacturer CNC Sheet Metal Shear Cutting Machie,good Selling QC12y-6x3200 Hydraulic Shearing Machine
Product Details
| Condition | New | CNC or Not | Normal | |
| Power Source | Mechanical | Place of Origin | Anhui, China | |
| Brand Name | yuanyi | Model Number | QA34-16 | |
| Voltage | 380V/220V Optional | Power(W) | 4KW | |
| Weight | 2830kg | Dimension(L*W*H) | 2885*1290*2460 | |
| Certification | CE ISO | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Features:
The machine adopts mechanical driving, the frame adopts cast steel, steel welded structure which has sufficient strength and rigidith, The machine is an ideal equipment for cutting square bar, angle round bar, Channel and joist, as well as punchine and notching.
Technial Parameters:
| Model | QA35-16 |
| Punching Pressure(T) | 63 |
| Max.cutting thickness of steel pltes(mm) | 16 |
| Plate strength(N/mm2) | ≤450 |
| Angle of Shear | 13 |
| A trip size(T×W)(mm) | 20×140 |
| Slider trip(mm) | 26 |
| Trips frequency(times/min) | 36 |
| Throat depth(mm) | 450 |
| Punch depth(mm) | 16 |
| Max.punching diameter(mm) | 28 |
| Main Motor Power(KW) | 4 |
| Overall diamensions(L×W×H)(mm) | 2885×1290×2460 |
Model you can choose:
| Model | Q35-16 | QA34-25 |
| Punching Pressure(T) | 63 | 110 |
| Max.cutting thickness of steel pltes(mm) | 16 | 26 |
| Plate strength(N/mm2) | ≤450 | ≤450 |
| Angle of Shear | 13 | 11 |
| A trip size(T×W)(mm) | 20×140 | 28×160 |
| Slider trip(mm) | 26 | 36 |
| Trips frequency(times/min) | 36 | 25 |
| Throat depth(mm) | 450 | 600 |
| Punch depth(mm) | 16 | 25 |
| Max.punching diameter(mm) | 28 | 35 |
| Main Motor Power(KW) | 4 | 7.5 |
| Overall diamensions(L×W×H)(mm) | 2885×1290×2460 | 1877×1945×725 |
Pictures:
