ChangAn 4X2 Minnitype LED Advertisement Truck

FOB Price

US$ 15,200 - 29,500 / Set

1 Set(Min. Order)

Port any port in China as your request.
Payment TermsT/T PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hubei, China		Brand Name	ChangAn
Model Number	SC1027DB		Usage	Outdoor

Product Description

ChangAn 4X2 minnitype LED advertisement truck

Product Description

ChangAn4X2 minnitype ad truck

1. We are the manufacturer.

2. OEM is OK.

3. ISO certificate.

Packaging & Shipping

Packaging Details:	Nude/ Ro-ro ship / Bulk transport / Container packing / SKD / etc. and it can be offered according to your request.
Delivery Detail:	10 to 25 days after receiving your payment(T/T,L/C)

Main Specifition

Technical parameters
The totalmass(kg)	2150	Curb Weight(kg)	1720
Rated the quality of(kg)	300	Chassis Model	SC1027DB
Approach / departure angle(°)	34/18	Front overhang / rear overhang	560/1260
Dimensions(mm)	4720×1830×2533,2590,2890	Compartment dimension(mm)
Number of axes	2	Maximum speed	110
Tire Specifications	175/70R14LT	Number of tires	4
Front track	1360	Rear track	1360
Wheelbase	2900	Axle load	750/1400
Number of spring	-/6	Type of fuel	Gasoline
Emission Standards	Euro3/Euro4
Engine parameters
Engine Model	JL466Q1	Engine Manufacturer		Chongqing Changan Automobile Co., Ltd.
Engine Displacement	1012	Engine power		50.7
Chassis Description	1. 4x2 chassis, with left/right hand drive optional, flat cab with air conditioner 2.4 cylider diesel engine and EuroIII/ Euro IV, 6 shift gearbox 3.steering control and air break
Modified Description	1. All-color LED panel at two sides(Water proof high light P10 vehicle-mounted LED screen), screen size:3840x1760mm, area: 6.8 m3. 2. 5mm composite steel frame box, outside with cold-roll steel sheets and aluminium sheet inside, wood floor, top grade plastic flooring; 3.Four hydraulic landing legs, mechatronics control;Circulating ventilation cooling system; High-performance silent diesel generator set; Kilometer streaming media control system control system;
Component	chassis,screen,power supply system(380V),hydraulic system(partly),operating system.
Purpose	This truck is commonly used in product promotion, brand promotion, draft activities, sales demonstrations, sporting event, concerts etc.
Product advantage	High quality with best price.
