UL Approved 4 Poles AC dp Contactors (SA-4P-40A-24VAC)

SA-4P-40A-24VAC

Features
   1) Name of product: 4 poles 40FLA definite purpose contactor
   2) Model Number: SA-4P-40A-24VAC
   3) Agency approvals: UL 508,ARI 780
   4) EN 60947-4-1 (AC1-40A / AC3-30A)
   5) Coil: 24VAC/110VAC/208-240VAC/277VAC/480VAC for choose
   6) Cetificate: ISO 9001:2000 UL CUL list,UL CUL recognized, CE certificate,SEMKO certificate,RoHS compliant.

Packing
   25pcs/box
   Box dimensions: 54*39.5*10cm   17KGS/16KGS

   Please contact with our sales team for detailed specification and price.

→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→→

We are manufacturing different kinds of  definite purpose contactor.See following detailed

information and contact with our sales team for more detailed information.

Feature

Hecheng SA series Definite Purpose Contactors are suitable for commercial applications including air conditioning, refrigeration, resistive heating, lighting and many other installations where a low cost, high performance contactor is needed. These devices offer flexibility and are designed to meet or exceed electrical and mechanical requirements as defined by Definite Purpose Contactors standards of USA/Canada.

Range

The SA Series Definite Purpose Contactors series product line is available in 1,1.5, 2, 3,4 poles contactors rated to from 24V to 600V AC. Current load rated at 20FLA,25FLA,30FLA,40FLA,50FLA,60FLA,75FLA,90FLA,120FLA available.

Flexibility and convenience

SA series Definit Purpose contactors series are compact in size and offer three convenient methods of wire connection: quick connect terminals, screws or box lugs. These models are supplied as standard with combination quick connect terminals and screws that accept hex, slotted or Phillips screwdrivers. Also can supply the Auxiliary Switches together with the Definite Purpose Contactor.

Standards & Approvals

Designed to meet or exceed UL, CSA standards Compliance to UL 508,ARI780/790 & CSA 14 UL CUL and CE approval
ISO 9001:2000 certified company Hecheng Electrical Co., Ltd. is located in Mingguan city, Anhui province, enjoying convenient transportation. We are one of the leading manufactures specializing in developing and producing all kinds of high or low voltage electrical products and accessories in China.

Besides European and American advanced technology and Chinese wisdom and diligence, adopting advanced and standard testing equipment from Europe and the USA, we have the support from European and American technologists
