Wireless Security System With 99 Wireless Zones and Easy Operation

Specifications

wireless security system with 99 wireless zones and easy operation:

Model:CX-3A

Features:

1.Independent keypad for operation, novelty style, simple operation.

2.It can store 9 group alarm telephone numbers 1-5 groups are common alarm number, the 6^th is alarm number for network alarm center,the 7^th is for away arm information upload, the 8^th is for stay arm information upload, the 9^th is for disarm information upload.

3.It can login 10 remote controllers.

4.It has 99 wireless defense zones, can login 1 detector to each zone, each zone has delay alarm, delay time is set by user, the main host can recognize the type of smoke detector and gas detector automatically.

5. Can take record for 10 seconds , automatic playback after complete recording.

6.Use automatic study login between detector and main host, the expansion is simple and convenient, and can delete detector in any zone arbitrarily.

7.Information protection, all information set can be finished main board or by remote controller, avoid purposeful change.

8.Power protection, all information is stored in memory components, no loss when power interruption.

9.Anti-rob help, press emergent key on the remote controller when something emergent happens, it will dial the preset telephone number silently for help.

10.Alarm priority: when telephone is busy, the main host will give priority for alarm.

11.Insist various arm/disarm mode: away arm, stay arm, disarm.

12.Remote control function for arm, disarm, interphone, listen-in after password check when at distant place.

13.It can network, send alarm information with standard LONGWAY format and CID format, choose communication mode automatically, ID code is 4 digitals.

14.Line-cut alarm: when telephone line is cut, the main host will start siren for 1 min. This function can be opened or closed.

15.Internal rechargeable battery in main host, guarantee normal work within 10hrs after power interruption.

16.Restore default parameters: detectors which already login and for record content can not be restored. The restore password is 1234, this operation will delete all telephone number, all function sets back to default state.

17.It has internal and external siren, when connects with external siren, the internal siren will closed automatically.

18.Anti-damage: when disassemble main host shell, the main host will give alarm and dial telephone number.

19.Power off and start: when only standby power is provided, power off or start can be made by power off key on the keyboard.

Main Unit parameters:

• Power supply: AC 220V±20%  DC 9V  300mA
• Static current: ≤ 30mA
• Alarm Current: ≤ 250mA
• Standby power:6V nicked hydrogen chargeable battery group
• Receive frequency: 433MHZ±1MH
• Ambient temperature: -10°C ~ 50°C
• Relative humidity: <80%
• Dimension: 143×148×43mm
• DB output: internal siren ≥90db within 1m    external siren
• Dialing parameters: -7±2dBM(high-frequency group) -9±2dBM(low-frequency group)

Optional accessories:

       Realizing the GSM dialing, through GSM dialer.
