Small CNC pcb drilling machine(TC-6060)

Specifications

Small CNC pcb drilling machine (TC-6060XB)

Product features:

• With 600*600MM engraving range;

• With 2.2KWspindle, can enhance the efficiency of engraving work;

• With whole casting iron frame, to ensure the structure stability, low inertia and no distortion;

• Equipped with high-speed spindle motor, high-performance division drive to ensure the long
• time and stable working;

• Adopted with advanced controlled system, with simple operating software, it’s easy to
• learn; And the operator can check the real-time trajectory, plus or minus Z-axis depth in real-
• time, and adjust the motor speed conveniently;

• Powerful compatibility for most of software such as: type3, Artcam, Proe, Wentai a variety of
• CAD / CAM;

• Humanized design, convenient for removing and installing;

• Can meet the high sensitivity, high accuracy, high speed small sculpture.

• Suitable for various kinds of metal mould engraving, such as aluminum, copper, gold, and many
• other elaborate deminded materials.

Motion Control System
	The PCIMC control card is designed by Weihong technology company of Shanghai, specialized for NC STUDIO Motion Control System. The card will be inserted into the PCI card slot of the computer, and the operation of the CNC engraver is controled by the control card. We have PCIMC-3D/6B/ 6A , optional
Driving Motor
	The Driving Motor is the executive component of the automatic control system, it works with the simple push of a button. The motor we use for our CNC engraver can be steping motor/ Servo motor, and the brand is optional. AC Servo motor is more popular for its advantages on performance and accuracy, but more costly. The brand can be Dongneng/ Yaskawa/ Mitsubishi/ Panasonic, etc. With different prices.
Frequency Converter
	The frequency converter is an equipment to control the AC motor by adjusting the frequency of the motor power. So it can offer actual voltage to the motor as per the practical need of motor, to make sure of energy conservation and speed regulation. Besides, the converter can protect the motor from over current, over voltage, overloaded, etc. Each spindle motor is connected with a independent frequency converter, it's more safe and timeproof.
Main Spindle
	There are two kinds of spindle: Water cooling and Air cooling spindles. And with different power options: 1.5KW/ 2.2KW/ 3.0KW/ 4.5KW, etc. With AC220V voltage, and speed can be 0-24000(R/Min). The output voltage and frequency can be adjusted timely by a frequency converter. Advantage: work with high frequency, stable, low noise, fast heat dissipation, and long operating life.
Guide rail and sliding block
	We use Linear square guide rails offered by HIWIN of Taiwan. The coefficient of rolling friction is small and positioning accuracy is much higher than sliding friction. The accuracy can be at μm level. It can work with high speed and low power dissipation, and can easily be assembled and replaced.
Dual screw-nut anti-gap rod
	The ball screw is an element to change the movements of the bearing from sliding to rolling. There are many roll balls between the screw shaft and the screw nut, and the balls rolling fast when the machine working. For the coefficient of rolling friction is smaller, the positioning accuracy is much higher. The accuracy of ball screw is higher than linear guide rail, and we have different brands optional.

Pictures of sample:

We are professional manufacturer of all kinds of CNC engraving machines, suitable for various of materials, such as: wood, stone, jade, acrylic, metal, ceramics, etc. Platform material

And we offer all kinds of CNC parts.

To know more about our products, please feel free to contact with us !
