Home > Products > * Grinding Machine > M1408x300 internal and external grinding machine
M1408x300 internal and external grinding machine
Negotiable
/ Set
1 Set(Min.Order)
- 20 Set / Sets per Month
- Qingdao
- T/T
You May Like
Product Details
| Condition | New | Type | Surface Grinding Machine | |
| CNC or Not | Normal | Place of Origin | Shaanxi, China | |
| Brand Name | YuanHang | Model Number | M1408x300 |
Product Description
Specifications
1.CE,standard2.No.1 quality in the market
3.High quality to price ratio
4.spare parts suppor
| Specification | Unit | M1308x300 | M1408x300 |
| Grinding dia.(OD/ID) | mm | 2-80 | 2-80/10-60 |
| Grinding length(OD/ID) | mm | 300 | 300/125 |
| Center height | mm | 115 | |
| piece weight | kg | 10 | |
| Worktable speed | m/min | 0.1-4 | |
| Wheel peripheral velocity | m/sec | 35 | |
| Max travel of table | mm | 340 | |
| Swivel range of worktable | ° | -3° +7° | |
| External wheel size | mm | Max 250x25x75 | Max 180x25x75 |
| Internal wheel spindle rotating-speed | r/min | 16000 | |
| Workhead and tailstock center | morse | NO.3 | |
| Overall dimensions(LxWxH) | mm | 1360x1240x1000 | |
| Machine weight | kg | 1500 | |
| Total motor power | kw | 2.34 | |
| Working Accuracy | |
| Roundness | 1.5/2.5um (OD/ID) |
| Surface roughness | Ra0.25/0.63um (OD/ID) |
| Uniformity of dia. In longitudinal section | 5/8um (OD/ID) |
