Home > Products > Power > HUAWEI NE20E-S NE20E-S16 CR2M0DPUDC11 NE20E-S16 DC Power Distribution Unit

HUAWEI NE20E-S NE20E-S16 CR2M0DPUDC11 NE20E-S16 DC Power Distribution Unit

FOB Price

US$ 1.00 - 10.00 / Piece

1 Piece(Min. Order)

Port Beijing
Payment TermsPayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Type	Wired
Application	Enterprise	Function	Firewall, QoS, VPN
LAN Ports	Other	WAN Ports	Other
Certification	FCC CE ROHS	Brand Name	HUAWEI
Model Number	CR2M0DPUDC11	Place of Origin	Beijing, China

Product Description

NE20E-S Universal Service Router Product Brochure

NetEngine (NE20E-S) Series Universal Service Routers are high-end network products developed for transportation, finance, electricity, government, education, and enterprise networks. They serve as aggregation nodes for IP backbone networks, core nodes on small and medium enterprise networks, edge nodes on campus networks, and access nodes on small and medium education networks.

NE20E-S routers run on the Versatile Routing Platform (VRP) operating system and use Huawei-developed NP chips and hardware-based forwarding and non-blocking switching technologies. They have the following features:

Line-rate forwarding, carrier-class reliability, excellent scalability, a well-designed Quality of Service (QoS) mechanism, and strong service processing capabilities
Layer 2 Virtual Private Network (L2VPN), L3VPN, multicast, Multicast VPN (MVPN), Multiprotocol Label Switching (MPLS) Traffic Engineering (TE), and QoS for carrier-class transmission reliability
Generic Routing Encapsulation (GRE), IP Security (IPSec), Network Address Translation (NAT), and NetStream Support for IPv6 and smooth transition from IPv4 to IPv6

Advanced VRP platform

NE20E-S routers use the latest VRP8 platform, which is also used by the NE5000E core router. The VRP uses the Resilient Distributed Framework (RDF), with separated management plane, service plane, data plane, and monitoring module to increase system flexibility, reliability, manageability, and expandability.

The VRP system is mature. So far, more than 4 million sets are running on live networks. Its rich features and stability have proven themselves through a wide variety of applications.

Huawei-developed chips for flexibility

NE20E-S servers use built-in NP chips developed by Huawei to give them a flexible programmable architecture. Microcode programming can be used for new service deployment, without replacing hardware, to save money. In addition, this architecture shortens the technological innovation cycle and speeds up new service launches.

All-around reliability

NE20E-S routers provide 99.999% multi-level reliability at the equipment, network, and service levels for carrier-class service. Reliability protection levels include:

Equipment: NE20E-S routers provide redundant backup for key components. The components support hot swap and hot backup. The NE20E-S series uses technologies, such as Non-Stop Routing (NSR), Non-Stop Forwarding (NSF), and In-Service Software Upgrade (ISSU) to ensure uninterrupted service forwarding
Network: Network-level reliability comes from IP Fast Re-Route (FRR), Label Distribution Protocol (LDP) FRR, VPN FRR, TE FRR, hot standby, fast convergence of Interior Gateway Protocols (IGP), BGP, and multicast routes, Virtual Router Redundancy Protocol (VRRP), trunk load balancing and backup, hardware-based Bi-directional Forwarding Detection (BFD) of 3.3 ms, MPLS OAM, and Ethernet OAM. The NE20E-S routers provide an end-to-end protection switching speed of 200 ms with no service interruption
Service: Huawei provides service-level reliability for L2VPNs and L3VPNs with VPN FRR, E-VRRP, VLL FRR, Ethernet OAM, and PW redundancy. These technologies ensure stable and reliable service operation with no service interruption

Flexible Virtual System (VS) technology

A physical router can be divided into multiple logical routers with resources separated between them. Services can be deployed on different VSs to form a multi-service network with service separation. VSs enhance security and reliability.

Product specifications

Item	NE20E-S2E	NE20E-S2F	NE20E-S4	NE20E-S8	NE20E-S16
Switching Capacity	160 Gbit/s	320 Gbit/s	480 Gbit/s	480 Gbit/s	480 Gbit/s
Forwarding Performance	70 Mpps	150 Mpps	180 Mpps	360 Mpps	360 Mpps
Fixed Ports	2 x 10 GE (SFP+) and 24 x GE (SFP)	4 x 10 GE (SFP+) and 40 x GE (SFP)	--	--	--
Number of Slots	2 PICs	2 PICs	2 MPUs 1 NSP 4 PICs	2 MPUs 2 NSPs 8 PICs	2 MPUs 2 NSPs 16 PICs
Dimensions (H x W x D)	3.5 in. x 17.4 in. x 8.6 in. = 2U (89 mm x 442 mm x 220 mm = 2U)	3.5 in. x 17. 4 in. x 8.6 in. = 2U (89 mm x 442 mm x 220 mm = 2U)	5.1 in. x 17.4 in. x 8.6 in. DC = 3U (132 mm x 442 mm x 220 mm DC = 3U) 7.0 in. x 17.4 in. x 8.6 in. = 4U (178 mm x 442 mm x 220 mm AC = 4U)	8.7 in. x 17.4 in. x 8.6 in. DC = 5U (222 mm x 442 mm x 220 mm DC = 5U) 10.3 in. x 17.4 in. x 8.6 in. AC = 6U (264 mm x 442 mm x 220 mm AC = 6U)	13.8 in. x 17.4 in. x 8.6 in. = 8U (353 mm x 442 mm x 220 mm = 8U)
Power consumption (in full configuration)	195W (DC) 219W (AC)	309W (DC) 335W (AC)	398W (DC) 456W (AC)	645W (DC) 703W (AC)	696W (DC) 740W (AC)
Weight in Full Configuration	20.5 lb (9.3 kg) (DC) 22.7 lb (10.3 kg) (AC)	20.7 lb (9.4 kg) (DC) 22.9 lb (10.4 kg) (AC)	30.2 lb (13.7 kg) (DC) 39.9 lb (18.1 kg) (AC)	49.1 lb (22.3 kg) (DC) 59.5 lb (27.0 kg) (AC)	74.9 lb (34.0 kg) (DC) 79.3 lb (36.0 kg) (AC)
Interface Types	40 GE 10 GE GE/FE OC-3c/STM-1c POS OC-12c/STM-4c POS Channelized OC-3/STM-1 POS E1/CE1
Clock Synchronization	Synchronous Ethernet and IEEE 1588v2
Layer 2 Features	IEEE 802.1q IEEE 802.1p IEEE 802.3ad IEEE 802.1ab STP/RSTP/MSTP
IPv4/IPv6 Routing Protocols	IPv4 static routes and dynamic routing protocols, such as RIP, OSPF, IS-IS, and BGP IPv4/IPv6 dual stack IPv4-to-IPv6 transition technologies, such as manual tunnel, 6-to-4 tunnel, and 6PE IPv6 static routes and dynamic routing protocols, such as BGP4+, RIPng, OSPFv3, and IS-ISv6 IPv6 neighbor discovery, PMTU discovery, TCP6, ping IPv6, tracert IPv6, socket IPv6, and IPv6 policy-based routing
L2/L3 VPN	LDP over TE, VPLS, H-VPLS, and VPN policy-based routing Martini MPLS L2VPN VLL/VPLS accessing L3VPN MPLS/BGP L3VPN and inter-AS VPN
Multicast	IGMPv1/v2/v3 IGMP snooping IPv6 multicast Static multicast routing PIM-SM PIM-SSM MBGP NG MVPN
QoS	WRED Five-level HQoS VLL/PWE3 QoS
Reliability	NSR for OSPF/RIP/LDP/RSVP-TE/PIM/MSDP/IGMP/ARP/L3VPN/IS-IS/BGP/VLL/VRRP GR for BGP/OSPF/IS-IS/LDP/VLL/VPLS/RSVP/L3VPN/PIM BFD for static route/fast reroute/VRRP/IS-IS/OSPF/BGP/PIM/LSP/IPv6 Fast convergence of BGP/IGP/multicast routes IP/LDP FRR, TE FRR, VPN FRR, and VLL FRR Ethernet OAM, Y.1731, and PWE3 E2E protection ISSU and in-service patching for smooth software upgrades
Security	ACL-based packet filtering AAA SNMPv3 encryption and authentication URPF, GTSM, DHCP snooping ARP attack defense SSHv2
Value-added Services	NAT, IPSec, GRE, and NetStream
OAM	Y.1731, IP FPM, MPLS OAM, 802.1ag, and 802.3ah
Operating Temperature	23°F to 147°F (-5°C to 65°C)	23°F to 147°F (-5°C to 65°C)	-40°F to 149°F (-40°C to 65°C)	-40°F to 149°F (-40°C to 65°C)	32°F to 113°F (0°C to 45°C)
Operating Relative Humidity	5% to 85%, non-condensing
Operating Altitude	≤ 9,842.5 ft. (3,000m)

Ordering information

Type	Description
NE20E-S Basic Configuration	NE20E-S16 DC Basic Configuration
	NE20E-S16 AC Basic Configuration
	NE20E-S8 DC Basic Configuration
	NE20E-S8 AC Basic Configuration
	NE20E-S4 DC Basic Configuration
	NE20E-S4 AC Basic Configuration
	NE20E-S2F DC Basic Configuration
	NE20E-S2F AC Basic Configuration
	NE20E-S2E DC Basic Configuration
	NE20E-S2E AC Basic Configuration
	Network Service Processor (NSP-50-E, apply for -40 to 65 degree scenarios)
	Network Service Processor (NSP-120-E, apply for -40 to 65 degree scenarios)
	Network Service Processor (NSP-A)
	Network Service Processor (NSP-B)
NE20E-S Line Card	1-Port 40G Base-CFP Physical Interface Card
	4-Port 10G Base LAN/WAN-SFP+ Physical Interface Card
	2-Port 10G Base LAN/WAN-SFP+ Physical Interface Card
	2-Port 10G Base LAN/WAN-SFP+ Physical Interface Card H
	1-Port 10G Base LAN/WAN-SFP+ + 8-Port 100/1,000 Base-X-SFP Physical Interface Card
	10-Port 100/1,000 Base-X-SFP Physical Interface Card
	10-Port 100/1,000 Base-X-SFP Physical Interface Card H
	8-Port 100/1,000 Base-RJ45 Physical Interface Card
	4-Port OC-3c/STM-1c POS-SFP Physical Interface Card
	2-Port OC-3c/STM-1c (or 1-Port OC-12c/STM-4C) POS-SFP Physical Interface Card
	4-Port Channelized STM-1c POS-SFP Physical Interface Card
	1-Port Channelized STM-1c POS-SFP Physical Interface Card
	32-Port E1 Physical Interface Card (75 ohm)
	32-Port E1 Physical Interface Card (120 ohm)
	16-Port E1 Physical Interface Card (75 ohm)
	16-Port E1 Physical Interface Card (120 ohm)
Software	NE20E-S Series Base SW, VRP8, V800R007
	NE20E-S Series 1588v2 Function License
	NE20E-S Series IP Performance Measure License (IP FPM)
	NE20E-S Series VxLan Function License
	NE20E-S Series Rn to R(n+1) Software Release Entitlement from Rn to R(n+1)

Packaging & Shipping

Package information: carton package with Huawei original package

Our Services

1.We can provide detail documents and remote help for device installation and configuration.
2. Warranty: 1 year. ( After the quality guarantee period began to charge appropriate maintenance service fee.)
3. Our company promises goods enjoy full return due to quality problem since goods delivered within 7 days or 15 days , returned goods must keep original state and it’s accessories are complete.
