Top grade manufacture top brand condensing unit
- ShangHai
- T/T
You May Like
Product Details
Place of Origin | Jiangsu, China | Brand Name | DeBitzer | |
Model Number | YC-CP | Type | Refrigeration Compressor | |
Application | Refrigeration Parts | Certification | CE |
Product Description
Top grade manufacture top brand condensing unit
Description of top brand condensing unit
nominal motor power HP/KW | 8/5.5 |
displacement(50HZ)m3/high pressure | 26.8 |
number of cylinder×diameter×stoke mm | 2× φ 64 × 48 |
oil injection volume L | 3.5 |
power supply V/d/HZ | 380~420/3/50 |
440 ~480/3/60 | |
elecrical parameter Maximum operating current/starting current/rotor locked current (A) | 13/41/74 |
Crankcase heater(220V)W | 120 |
oil supply method | Splash lubrication |
weight (including freezing oil)kg | 140 |
Refrigeration Scale
BFCA-0800 | Condensing temperature30 °C | Condensing temperature40 °C |
Evaporation temperature°C | Refrigerating capacity (kw) | Refrigerating capacity (kw) |
12.5 | 36.0 | 32 |
10 | 33 | 29.5 |
7.5 | 29.8 | 26.6 |
5 | 27 | 24.8 |
0 | 21.5 | 19.8 |
-5 | 19.3 | 17 |
-10 | 15.4 | 13.4 |
-15 | 12.4 | 10.5 |
-20 | 9.6 | 8.2 |
-25 | 7.3 | 6 |
-30 | 5.4 | 4.4 |
-35 | 3.8 | |
-40 | 2.5 |
use scope
item/Refrigerant | R22 | R134a | R404a | R407a | R407b | R407c |
Evaporating temperature | -40~+12.5°C | -20~+12.5°C | -40~+10°C | -40~-10°C | -40~-10°C | -30~+10°C |
Condensing temperature | 30-45°C |
Maximum pressure difference | 1.83MPA |
MAX compression ratio | 18 |
MAX .discharge temperature | 135°C(discharge pipe surface) |
Suction superheat | min:10KMAX:which maintains the discharge temperature below 135°C |
MAX oil temperature | 80°C |
Power supply | 3ph 380/440V 50/60HZ |
Motor temperature | below 105°C |
Refrigeration oil | suniso3GS/SUNISO SL32S |
Max ambient temperature | 43°C |
Picture of top brand condensing unit
we are a manufacturer and exporter of pu sandwichpanels, have more than 17 years experience in this field. Our main
products include: thermal insulation panels, removable cold rooms, half buried doors and slidng doors, refrigerating
compressors, cold room building accessories, aluminum decorative wall panels. The above products are produced by
ourselves, and because of so many years in this market, we could supply customers most things about cold room.
Below is our company profile
Located in Changzhou, near 312 National Highway, we are a private company specialized in manufacturing polyurethane sandwich panels, removable cold rooms, refrigerating compressor, aluminum decorative wall panel, and solar energy water heaters. The factory covering an area of 120,000 square meters, our company is equipped with the first-class production facilities. Since our establishment in 1992, a group of senior and medium-level technicians and experienced skilled workers have been employed and trained.
Our subsidiary factories include two pu panel automatic production line, 4 manual lines of hook panels, a compressor assembly factory, a stainless steel material factory, a polyurethane material workshop. Among them, the pu sandwich panel factory is equipped with a high-class automatic production line in China with the annual output reaching 120,000 square meters per year. Furthermore, the annual sales volume of the refrigeratory factory has taken the leading position for several years in the industry in China.
At present, our products with the brands of "Yongchun" are popular all over the country. Our company has experienced in the installation of large cold storage projects. Our products are exported to dozens of countries and regions and enjoy high popularity among our customers.
Led by the market, developing with renovation, and insisting on the policy of "Down-To-Earth, Dedication, Hard Work, Renovation", we are committed to creating a high-class company in new energy industry and making contribution to the development of new energy and renewable energy industries.
Process:
Factory:
Guarantee : 1 year.
Non-artificial damage, within one year free replacement. Don’t include freight
Certificate:
Trade Area:
Case:
