Product Details
Place of Origin | Jiangsu, China | Brand Name | Yongchun | |
Model Number | YC-CP | Type | Refrigeration Compressor | |
Application | Refrigeration Parts | Certification | CE |
Product Description
Bottom price stylish led water proof wall lights outdoor
As one of largest manufacturer and project developer in Changzhou city, Jiangsu Pro, we supply customers different kinds of cold room lamp
Also it is acceptable to use compressors customized for their projects, such as Copeland and Bitzer, the following is a expamle
of Bitzer parameters:
Picture of led water proof wall lights outdoor
Use scope
Description of led water proof wall lights outdoor
Refrieration | R22 | R134a | R404a | R407a | R407b | R407c |
Item | ||||||
Evaporating tempreture | -40-+12.5°C | -20-+12.5°C | -40-+10°C | -40--10°C | -40--10°C | -30-+10°C |
Condensing tempreture | 30-45°C(water cooled), 30-50 °C(air cooled) | |||||
ure difference | 1.83MPA | |||||
pression ratio | 18 | |||||
Max.discharge emperature | 135°C(discharge ppe surface) | |||||
Suction superheat | Min:10K, Max: Value which maintains the discharge temperature below 135°C | |||||
Max.oil tempreture | 80°C | |||||
Power supply | 3Ph 380/440V 50/60Hz | |||||
Motor temperature | Below 105°C | |||||
Refrigeration oil | SUNISO 3GSSUNISO SL32S | |||||
Max.ambient tempreture | 43°C |
Technical parameters
Compressor model | Nominal motor power HQ/KW | Displacemen (50Hz)cbm/h | Number of cylinder x Dameter x Stroke mm | Oil injection volume L | Power supply v HZ | Electrical paramater | Crankcase Heater(220v)w | Oil Supply | Weight (including freezing oil)Kg |
BFCA-0500 | 5/3.7 | low | High Pressure 18.4 | 2xD54 x46 | 1.85 | 380-420/3/50 440-480/3/60 | max pperating current 8.5 | starting current /rotor locked current 26/45 | 60 | Splash lubrication | 101 |
BFCA-0800 | 8/5.5 | 26.8 | 2XD64 x48 | 3.5 | 13 | 41/74 | 120 | 140 | |||
BFCA-1000 | 10/7.5 | 36 | 2XD64 X64 | 3.5 | 18.6 | 52/82 | 120 | 145 | |||
BFCA-1500 | 15/10.5 | 54 | 3XD64 X64 | 4.8 | 28 | 72/102 | 180 | 192 | |||
BF4FC-3.2 | 3/2.2 | 18.05 | 4XD41 X39.3 | 2.0 | 380-420YY/3 /50 440-480 YY/3/60 | 9.2 | 44.2 | 120 | centrifug al
lubricatio in | 82 | |
BF4FC-5.2 | 5/3.7 | 18.05 | 4XD41 X39.3 | 2.0 | 10.8 | 62.2 | 120 | 86 | |||
BF4EC-4.2 | 4/3.0 | 22.72 | 4XD46 X39.3 | 2.0 | 10.7 | 53.5 | 120 | 84 | |||
BF4EC-6.2 | 6/4.4 | 22.72 | 4XD46 X39.3 | 2.0 | 13.2 | 62.2 | 120 | 86 | |||
BF4DC-5.2 | 5/3.7 | 26.84 | 4XD50 X39.3 | 2.0 | 13.5 | 62.2 | 120 | 85.5 | |||
BF4DC-7.2 | 7/5.1 | 26.84 | 4XD50 X39.3 | 2.0 | 15.9 | 82.4 | 120 | 88.5 | |||
BF4CC-6.2 | 6/4.4 | 32.48 | 4XD55 X39.3 | 2.0 | 15.9 | 82.4 | 120 | 90.5 | |||
BF4CC-9.2 | 9/6.6 | 32.48 | 4XD46 X39.3 | 2.0 | 20 | 82.4 | 120 | 90.5 | |||
BF4VCS-6.2 | 6/4.4 | 34.73 | 4XD55 X42 | 2.6 | 14 | 39/68 | 140 | 129 | |||
BF4VCS-10.2 | 10/7.5 | 34.7 | 4XD55 X42 | 4XD55 X42 2.6 | 21 | 59/99 | 140 | 139 | |||
BF4TCS-8.2 | 8/5.5 | 41.33 | 4XD60 X42 | 2.6 | 17 | 49/81 | 140 | 134 | |||
BF4TCS-12.2 | 12/8.8 | 41.33 | 4XD60 X42 | 2.6 | 24 | 69/113 | 140 | 141 | |||
BF4PCS-10.2 | 10/7.5 | 48.5 | 4XD65 X42 | 2.6 | 21 | 59/99 | 140 | 139 | |||
BF4PCS-15.2 | 15/10.5 | 48.5 | 4XD65 X42 | 2.6 | 31 | 81/132 | 140 | 142 | |||
BF4NCS-12.2 | 12/8.8 | 56.25 | 4XD70 X42 | 2.6 | 24 | 69/113 | 140 | 141 | |||
BF4NCS-20.2 | 20/15 | 56.25 | 4XD70 X42 | 2.6 | 37 | 97/158 | 140 | 150 | |||
BF4J-13.2 | 13/9.6 | 63.5 | 4XD65 X55 | 4.5 | 380-420 YY/3/50
440-480 YY/3/60 | 27 | 81/132 | 140 | 193 | ||
BF4J-22.2 | 22/16.2 | 63.5 | 4XD65 X55 | 4.5 | 39 | 97/158 | 140 | 202 | |||
BF4H15.2 | 15/10.5 | 73.6 | 4XD70 X55 | 4.5 | 31 | 81/132 | 140 | 197 | |||
BF4H-25.2 | 25/18.5 | 7.6 | 4XD70 X55 | 4.5 | 45 | 116/193 | 140 | 205 | |||
BF4G-20.2 | 20/15 | 84.5 | 4XD70 X55 | 4.5 | 37 | 97/158 | 140 | 200 | |||
BF4G-30.2 | 30/22 | 84.5 | 4XD75 X55 | 4.5 | 53 | 135/220 | 140 | 209 |
Compressor photo
we are a manufacturer and exporter of pu sandwichpanels, have more than 17 years experience in this field. Our main
products include: thermal insulation panels, removable cold rooms, half buried doors and slidng doors, refrigerating
compressors, cold room building accessories, aluminum decorative wall panels. The above products are produced by
ourselves, and because of so many years in this market, we could supply customers most things about cold room.
Below is our company profile
Located in Changzhou, near 312 National Highway, we are a private company specialized in manufacturing polyurethane sandwich panels, removable cold rooms, refrigerating compressor, aluminum decorative wall panel, and solar energy water heaters. The factory covering an area of 120,000 square meters, our company is equipped with the first-class production facilities. Since our establishment in 1992, a group of senior and medium-level technicians and experienced skilled workers have been employed and trained.
Our subsidiary factories include two pu panel automatic production line, 4 manual lines of hook panels, a compressor assembly factory, a stainless steel material factory, a polyurethane material workshop. Among them, the pu sandwich panel factory is equipped with a high-class automatic production line in China with the annual output reaching 120,000 square meters per year. Furthermore, the annual sales volume of the refrigeratory factory has taken the leading position for several years in the industry in China.
At present, our products with the brands of "Yongchun" are popular all over the country. Our company has experienced in the installation of large cold storage projects. Our products are exported to dozens of countries and regions and enjoy high popularity among our customers.
Led by the market, developing with renovation, and insisting on the policy of "Down-To-Earth, Dedication, Hard Work, Renovation", we are committed to creating a high-class company in new energy industry and making contribution to the development of new energy and renewable energy industries.
Process:
Factory:
guarantee : 1 year.
Non-artificial damage, within one year free replacement. Don’t include freight
Certificate:
Trade Area:
Case:
WE ARE FAST
HERE IN CHANGZHOU, WE ARE ONE OF THE TWO ONLY FACTORIES WHO OWN THE AUTOMATIC PRODUCTION LINE,
OTHERS BUY THIS TYPE OF PANELS FROM US.
