Cisco Catalyst 4500X 750W DC Power Supply
- Shenzhen/Hongkong
 - Credit Card PayPal

You May Like
Product Details
| Place of Origin | China | Brand Name | Cisco | |
| Model Number | C4KX-PWR-750DC-F= | Output Power | 301 - 400W |
Product Description
Specifications
Catalyst 4500X 750W AC front to back cooling 2nd PWR supply1.Original new sealed
2.High quality&Best Price
Cisco Catalyst 4500-X Series Switch (Figure 1) is a fixed aggregation switch that delivers best-in-class scalability, simplified network virtualization, and integrated network services for space-constrained environments in campus networks. It meets business growth objectives with unprecedented scalability, simplifies network virtualization with support for one-to-many (Cisco Easy Virtual Networks [EVN]) and many-to-one (Virtual Switching System [VSS]) virtual networks, and enables emerging applications by integrating many network services.
| C4KX-PWR-750DC-F= | Catalyst 4500X 750W DC back to front cooling power supply |
| Power Supply Information for Cisco Catalyst 4500-X Series | |
Power Supply Feature  | Support in the 4500-X Series |
| AC Power Max Rating | 750W |
| System Power Consumption | 330W nominal/400W max |
| Input-Voltage Range and Frequency | AC 100 to 240 VAC 50-60 Hz/DC -72 VDC to -40 VDC |
| DC Power Max Rating | 750W |
| AC to DC failover and vice versa | Yes |
| Total Output BTU (Note: 1000 BTU/hr = 293W) | 1122 BTU/hr (330 W) nominal/1365 BTU/hr (400 W) max |
| Input Current | AC 11A @ 110VAC, 6 A @ 200VAC/DC 25A Max |
| Output Ratings | 12V @ 62A & 3.3V @ 3A |
| Output Holdup Time | AC = 16 ms; DC = 4 ms @ maximum load |
| Power-Supply Input Receptacles | AC IEC 60320 C15/DC Custom detachable screw terminal (supplied) |
| Power Cord Rating | AC 15A/DC 25A |
| Ordering Information | |
Product Number  | Description |
| Base Switch PIDs | |
| WS-C4500X-16SFP+ | Catalyst 4500-X 16 Port 10GE IP Base, Front-to-Back Cooling, No P/S |
| WS-C4500X-24X-IPB | Catalyst 4500-X 24 Port 10GE IP Base, Front-to-Back Cooling, No P/S |
| WS-C4500X-24X-ES | Catalyst 4500-X 24 Port 10GE Enterprise Services, Front-to-Back Cooling, No P/S |
| WS-C4500X-32SFP+ | Catalyst 4500-X 32 Port 10GE IP Base, Front-to-Back Cooling, No P/S |
| WS-C4500X-40X-ES | Catalyst 4500-X 40 Port 10GE Enterprise Services, Front-to-Back Cooling, No P/S |
| C4KX-NM-8SFP+ | Catalyst 4500-X 8 Port 10GE Network Module |
| WS-C4500X-F-16SFP+ | Catalyst 4500-X 16 Port 10GE IP Base, Back-to-Front Cooling, No P/S |
| WS-C4500X-F-32SFP+ | Catalyst 4500-X 32 Port 10GE IP Base, Back-to-Front Cooling, No P/S |
| FRU and OIR FANs | |
| C4KX-FAN-F | Catalyst 4500-X Back-to-Front Cooling Fan |
| C4KX-FAN-R | Catalyst 4500-X Front-to-Back Cooling Fan |
 Power Supply  | |
| C4KX-PWR-750AC-F | Catalyst 4500-X 750W AC Back-to-Front Cooling Power Supply |
| C4KX-PWR-750AC-R | Catalyst 4500-X 750W AC Front-to-Back Cooling Power Supply |
| C4KX-PWR-750DC-F | Catalyst 4500-X 750W DC Back-to-Front Cooling Power Supply |
| C4KX-PWR-750DC-R | Catalyst 4500-X 750W DC Front-to-Back Cooling Power Supply |
| Accessories | |
| CAB-CON-C4K-RJ45 | Console Cable 6ft with RJ-45-to-RJ-45 |
| SD-X45-2GB-E | Cisco Catalyst 4500 2-GB SD card |
| USB-X45-4GB-E | Cisco Catalyst 4500 4-GB USB device |
 Software  | |
| S45XU-33-1511SG | Cisco IOS Software XE Release 3.3.0 SG non-crypto universal image for Cisco Catalyst 4500-X 32-port and 40-port models |
| S45XUK9-33-1511SG | Cisco IOS Software XE Release 3.3.0 SG crypto universal image for Cisco Catalyst 4500-X 32-port and 40-port models |
| S45XU-331-1511SG | Cisco IOS Software XE Release 3.3.1 SG non-crypto universal image for Cisco Catalyst 4500-X 16-port and 24-port models |
| S45XUK9-331-1511SG | Cisco IOS Software XE Release 3.3.1 SG crypto universal image for Cisco Catalyst 4500-X 16-port and 24-port models |
| S45XU-34-1512SG | Cisco IOS Software XE Release 3.4.0 SG non-crypto universal image for all Cisco Catalyst 4500-X models |
| S45XUK9-34-1512SG | Cisco IOS Software XE Release 3.4.0 SG crypto universal image for all Cisco Catalyst 4500-X models |
| C4500X-LIC= | Base product ID for software upgrade licenses on Catalyst 4500-X (paper delivery) |
| C4500X-IPB | Catalyst 4500-X IP BASE software license (paper delivery) |
| C4500X-16P-IP-ES | Catalyst 4500-X IP BASE to Enterprise Services upgrade license (paper delivery) for 16-port and 24-port models |
| C4500X-IP-ES | Catalyst 4500-X IP BASE to Enterprise Services upgrade license (paper delivery) for 32-port and 40-port models |
| L-C4500X-LIC= | Catalyst 4500-X Base product ID for software upgrade licenses (electronic delivery) |
| L-C4500X-IPB | Catalyst 4500-X IP BASE software license (electronic delivery) |
| L-C4500X-16P-IP-ES | Catalyst 4500-X IP BASE to Enterprise Services upgrade license (electronic delivery) for 16-port and 24-port models |
| L-C4500X-IP-ES | Catalyst 4500-X IP BASE to Enterprise Services upgrade license (electronic delivery) for 32-port and 40-port models |
| C4KX-PWR-750AC-F/2 | Catalyst 4500X 750W AC back to front cooling 2nd PWR supply |
| C4KX-PWR-750AC-R/2 | Catalyst 4500X 750W AC front to back cooling 2nd PWR supply |
| C4KX-PWR-750DC-F= | Catalyst 4500X 750W DC back to front cooling power supply |
| C4KX-PWR-750DC-R= | Catalyst 4500X 750W DC front to back cooling power supply |
| C4KX-PWR-750AC-R= | Catalyst 4500X 750W AC front to back cooling power supply |
| C4KX-PWR-750AC-F= | Catalyst 4500X 750W AC back to front cooling power supply |
| C4KX-PWR-750DC-F/2 | Catalyst 4500X 750W DC back to front cooling 2nd PWR supply |
| C4KX-PWR-750DC-R/2 | Catalyst 4500X 750W DC front to back cooling 2nd PWR supply |
