Product Details
| Brand Name | Electronic | Model Number | F21-6S | |
| Use | Universal | Place of Origin | Henan, China |
Product Description
Crane wireless remote control
Specifications:
1. Crane wireless remote control for cranes, hoists, lifting mobiles
2. Single speed
3. CE approved
4. Control distance:100M
Basic specification:
| Transmitter | |
| Model | F21-6S |
| Single-speed button | 6 |
| Double-speed button | 0 |
| Emergency button | NO |
| Shell material | Glass fiber-reinforced nylon-6 |
| Battery | 2pcs AA battery |
| Battery life | >100 hours |
| Frequency | 310-330MHz |
| RF Power | <10DBm |
| Modulation system | FM |
| Control distance | 100m in ordinary conditions |
| IP rating | IP65 |
| Size | 16.4*7.5*4.6cm |
| Weight | around 320g |
| Temperature Rating | -35°C ~ +85°C(Regardless of the battery temperature tolerance) |
| I.D.Code | 4.3 billion |
| Voltage Warning | TX Red LED will flash slowly when the volts under 2.2V,and unable to start TX under 1.8V. |
| Fault Detection | TX Red LED is flashing quickly: TX LED will flash slowly: |
| RX Model | F21-6S-RX-V-(E) |
| RX Size | 18.7x8.6x7.9cm |
| RX Weight | about 624g ( without wire cable ) |
| Housing Material | glass fiber-reinforced nylon-6 |
| Protection Degree | IP65 |
| connection diagram | English |
| Temperature Rating | -35°C ~ +85°C |
| Power Supply | AC380V,AC36V,AC220V,AC110V,AC48V,AC24V, AC12V/DC12V,AC380V/AC220V(50-60Hz) |
| Relays | 6 Relays control functions,1 relay control EMS and 1 relay reserve |
| Output Relays | 5Amp Omniseal Relays(AC250V/10A Relays ,10Amp fuse) |
| I.D.Code | 4.3 billion |
| Operating Frequency | 310.0325-331.165MHz |
| Channel Spacing | 0.2675MHz |
| Channel | 80CH |
| Sensitivity | ≥-110DBm |
| Interface | Cable output |
Standard Configuration:
* It suitable for single hook single speed electric hoist type crane and the application of under 8 contacts
* Crane wireless remote control .
* One Transmitter 1pcs(with straps);
* One Receiver;
* One Receiver with 1meter cable ;
* Operation and Maintenance manual;
>> Wiring diagram
Packing:
1 set per box, 6 sets per carton
Producing ability :
Henan Yuding Company is the professional Crane wireless remote control manufacturer in China . We mainly Design, Manufacture, Installation, Repair , Maintenance, Trade and Export all kinds Electric Hoists controller, Overhead Cranes controller, Gantry Cranes controller, Jib Cranes,Tower Crane controller, Scissor Lift controller , etc.
Certificates:
Our Services
1.Clients Traning Services
We support our clients to master how to use our product in better and more efficient way if need.
2 .After Sale Service
We offer the Preventative Maintenance and After Sales Service. we strongly feels about the importance of supporting our customers and the product solutions we provide. We also offer two year guarantee period.
