8 Heads K Cup Filling and Sealing Machine
- Qingdao Port/Shanghai Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Plastic Bag Liquid Filling Sealing Machine
-
Electric Liquid Bag Filling and Sealing Machine
-
Automatic Liquid Filling Machine for Oil and Cosmetic
-
Automatic Cotton Swab Drying and Packing Machine/Cotton Swab Processing Machine
-
Whirly Lollipop Packing Machine | Lollipop Wrapping Machine | Packing Machine for Special Shape Lollipops
-
Whirly Lollipop Bagging Machine | Lollipop Packing Machine | Flat Lollipop Packing Machine
Product Details
| Condition | New | Application | Beverage, Chemical, Food, Medical | |
| Packaging Type | Other, Cup | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380V | Power | 4500W | |
| Place of Origin | Henan, China | Brand Name | TOPP | |
| Model Number | TPP-8J | Dimension(L*W*H) | 3800*800*1900 mm | |
| Weight | 1800kg | Certification | CE/IS9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
8 Heads K Cup Filling and Sealing Machine :
Introduction:
1. Automatic Japanese Omron PLC control system. Automatic cup dropping—plunger filling(leak-proof)—ultraviolet sterilization—cursor positioning—double hot seal—automatic film cutting—automatic film collecting—finished product automatic dropping
2. Machine material: machine frame is made of carbon steel 45#, which is coated by stainless steel metal plate. Other parts of machine are all made of stainless steel 304.
Technical parameters:
model | TPP-8J(2*4) |
Filling head | 8 heads |
Filling method | plug filling(leak-proof) |
Filling material | Liquid or semi-liquid |
capacity | 3500-3800cups/h |
Filling quantity | 30-300 g adjustable |
Filling accuracy | 2-3 g |
power | 4.5 kw |
Air consumption | 0.7m³/min |
Power supply | 380V/50HZ |
Temperature control | 0-400ºC |
Weight | 1800 KG |
Dimension | 3800*800*1900 mm |
Application and feature:
TPP-8Jautomatic cup filling sealing machine is suitable for kinds of shapes of plastic cups filling and sealing. Packed product is very beautiful and top grade. This machine is fully automatic from cup sending, filling, sealing, film collecting and cup discharging.
This machine is multi-functional model.
