Home > Products > Industrial class gasoline genset > 20kw/25kva 3-phase Gasoline Generator With Soundproof Canopy
20kw/25kva 3-phase Gasoline Generator With Soundproof Canopy
Negotiable
/ Unit
1 Unit(Min. Order)
- Chongqing
- T/T
You May Like
-
Kohler Engine Permanent Magnet Generator Set
-
10KW 50Hz 60Hz Air Cooled AC Single Phase Top Horizontal Magnetic Gasoline Generators
-
Air Cooled Mobile Gasoline Portable Generator 20kw
-
Briggs Engine Powered ac Single Phase Output Air Cooled Gasoline Generator Set 2kva
-
Three Phase Electric Start Non-electromagnetic Disturbance Fuel Energy Magnet Generator 12kw/12kva 230V/400V
-
Efficient 2 Pole ac 1 Phase Synchronous Brushless Excitation Generator 10kva
Product Details
| Place of Origin | Chongqing, China | Brand Name | YOHOU | |
| Model Number | YH14000ME | Output Type | AC Single Phase | |
| Speed | 3000rpm | Frequency | 50Hz | |
| Rated Power | 15kw 20kw 25kw 30kw | Rated Voltage | 230V |
Product Description
PMG 20kw/25kva 3-phase gasoline generator
Product Description
Advantage: Silent Gasoline Generator 15000 watt/20000 watt/25000 watt/30000 watt
1. Equipped with Automobile Gasoline engine, water cooled, 4 cylinders.
2. with permanent magnet alternator.
3. strong overload capacity, highly reliable, maintenance free, long service life, waterproof and dustproof.
4. No carbon brush, no electric park, no electromagnetic interference,
5. CE approval.
Technical Parameter
| Genset Model | YH18000MS | YH25000MS | YH30000MS | YH35000MS | |||||
| Engine | Gasoline Engine | 465F1 | 465F1 | 466F1 | JM491Q | ||||
| Power (HP) | 35 | 35 | 42 | 67 | |||||
| Cylinder | 4 | 4 | 4 | 4 | |||||
| RPM (R/MIN) | 3000(rated)/ 3600 (MAX.) | 3000(rated)/ 3600 (MAX.) | 3000(rated)/ 3600 (MAX.) | 3000(rated)/ 3600 (MAX.) | |||||
| Cooled Type | Water Cooled | Water Cooled | Water Cooled | Water Cooled | |||||
| Fuel Type | 93# pure gasoline | 93# pure gasoline | 93# pure gasoline | 93# pure gasoline | |||||
| Displacement (CC) | 1050 | 1050 | 1300 | 2230 | |||||
| Start Type | Electric Start | Electric Start | Electric Start | Electric Start | |||||
| Oil Alert Systrem | Yes | Yes | Yes | Yes | |||||
| Fuel Consumption (g/hp.hr) | 312 | 312 | 312 | 300 | |||||
| Fuel Capacity (L) | 25 | 25 | 26 | 40 | |||||
| Phase | Single/3 phase | Single/3 phase | Single/3 phase | Single/3 phase | |||||
| Excitation Type | Rare-earth permanent magnet | Rare-earth permanent magnet | Rare-earth permanent magnet | Rare-earth permanent magnet | |||||
| Rated Voltage (V) | 220/400 | 400 | 400 | 400 | |||||
| Power Factor (cos) | 1 | 1 | 1 | 1 | |||||
| Fequency (Hz) | 50 (rated)/60 (Max.) | 50 (rated)/60 (Max.) | 50 (rated)/60 (Max.) | 50 (rated)/60 (Max.) | |||||
| Rated Current (A) | 21.7 | 28.9 | 36 | 43.3 | |||||
| Rated Power (KW) | 15 | 20 | 25 | 30 | |||||
| Max. Power (KW) | 16 | 22 | 27 | 31 | |||||
| Protection Class | IP23 | IP23 | IP23 | IP23 | |||||
| Insulation Class | F | F | F | F | |||||
| Color | Orange | ||||||||
| Voice (dBA) 7 m | 65 | 65 | 65 | 65 | |||||
| L x W x H (mm) | 1150x780x790 | 1150x780x790 | 1150x780x790 | 1650x890x900 | |||||
| Net Weight (KG) | 360 | 380 | 420 | 480 | |||||
