WEICHAI Diesel Engine Generator Set
- Chongqing
- T/T
You May Like
Product Details
| Place of Origin | Chongqing, China | Brand Name | YOHOU | |
| Model Number | GF15WM | Output Type | AC 3 Phase | |
| Speed | 1500rpm | Frequency | 50Hz | |
| Rated Power | 12KVA 15KVA, 20KVA, 25KVA 30KVA | Rated Voltage | 230V 400V | |
| Rated Current | 21A |
Product Description
Open Frame WEICHAI diesel engine generator set
Advantage
1. WEICHAI diesel engine generator set
2. 50Hz.1500rpm/ac400V/230V, 3 phase 4 wires.
3. With permanent magnet generator alternator.
4. 12KVA 15KVA, 20KVA, 25KVA 30KVA .
Technical Parameter
| Model | GF10DWM | GF12DWM | |
| Genset Data | Prime Power (KW) | 10KW/10KVA | 12KW |
| Standby Power (KW) | 12KW/12KVA | 15KW | |
| Rated. Capacity (KVA) | 15KVA | ||
| Rated Power Factor | COSΦ=1 | COSΦ=1 | |
| Rated Voltage (V) | 230V | 230V | |
| Rated Current (A) | 43.5A | 52A | |
| Rated Frequency (Hz) | 50Hz | 50Hz | |
| Rated RPM | 1500 RPM | 1500 RPM | |
| Start | Hand start | Hand start | |
| Diesel | 0# light diesel | 0# light diesel | |
| Dimensions (L x W x H) | 1500×650×800mm | 1500×650×800mm | |
| Steady state voltage regulation (100%) | ≤±1 | ≤±1 | |
| Voltage fluctuation rate (100%) | ≤±0.5 | ≤±0.5 | |
| Transient voltage regulation rating | +20~-15 | +20~-15 | |
| Voltage stability time (S) | ≤1 | ≤1 | |
| Steady state frequency regulation (100%) | ≤±1 | ≤±1 | |
| Frequency fluctuation rate (100%) | +10~-7 | +10~-7 | |
| Frequency stability time (S) | ≤3 | ≤3 | |
| Fuel Consumption (100% load) | 210g/kW·h | 210g/kW·h | |
| Noise Level (LP7m) | 98dB(A) | 98dB(A) | |
| Dimensions (L x W x H) | 1500×650×800mm | 1500×650×800mm | |
| Weight (KG) | 480kg | 480kg | |
| Engine | Brand | WEICHAI diesel engine | WEICHAI diesel engine |
| Model | WP2.1D18E2 | WP2.1D18E2 | |
| Cylinder | 4 cylinders | 4 cylinders | |
| Bore x Stroke (mm) | 85×92 mm | 85×92 mm | |
| Compression Ratio | Ratio: 19:1 | Ratio: 19:1 | |
| Start Type | DC12V electric start | DC12V electric start | |
| Cooled Type | Water cooled | Water cooled | |
| Type | Direct Injection | Direct Injection | |
| Speed regulation Type | mechanical speed governors | mechanical speed governors | |
| Air Intake Syatem | natural aspiration | natural aspiration | |
| Overload Capacity | About 110% | About 110% | |
| RPM | 1500RPM | 1500RPM | |
| Generator | Brand | Chongqing Zhiren Electric | Chongqing Zhiren Electric |
| Model | 12S/M4 | 12S/M4 | |
| Excitation Sytem | Rare-earth Permanent magnet | Rare-earth Permanent magnet | |
| Rated Power (KW) | 12KW | 12KW | |
| Rated Voltage (V) | 230V | 230V | |
| Insulation Grade | H | H | |
| IP | IP23 | IP23 | |
| Wiring Connection Type | 3-phase 2 wires, | 3-phase 2 wires, | |
| Frequency (Hz) | 50Hz | 50Hz | |
| Rated Power Factor | COSΦ=1 | COSΦ=1 | |
| Loading | 20GP 5.89*2.35*2.39(m) | 12 sets | |
| 40GP 12.029*2.35*2.39(m) | 28 set | ||
Are you a factory or a trading company?
We are a professional and leading manufacturer.
Where are you company located in?
Our company is located in Jinfeng Electronic Industry Park, Jiulongpo District, Chongqing City, adjoins Chongqing Xiyong Bonded Zone.
What products are you produce?
We specialize in gasoline generator, gasoline generator, silent generator, movable generator, welder and related products.
What’s your annual capacity?
About 250,000 units.
What’s the MOQ?
Generally speaking, MOQ is 10 sets; we advise you to purchase 1*20GP or 1*40HQ.
What’s the delivery time?
About 21 days. It’s up to the quantities you buy.
