Reinforcement Steel
- XIN GANG Tianjin
- T/T
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | YUNTAO | |
| Model Number | TY-RFM1 | Frame Material | Metal | |
| Metal Type | Steel | Pressure Treated Wood Type | Nature | |
| Frame Finishing | Not Coated | Feature | Easily Assembled, Waterproof |
Product Description
Specifications
reinforcement steel1.Wire dia.:5.0-16mm
2.Opening:75-300mm
3.panel length:3-12m
4.panel width: 0.5-3.0m
reinforcement steel
1. Material
High quality low carbon steel wire, stainless steel wire.
2.Specification:
1. wire diameter: 5mm-16mm
2. opening: 50*50mm,50*100mm,50*200mm 100X100mm,100x150mm,150x150mm,200x200mm,etc
3. panel length:3-12m
4. panel width: 0.5-3.0m
3.Features
Good corrosion resistance
anti-aging
nice appearance
easy and quick installation
4.Application
reinforcing mesh are widely used in construction reinforcement, bridge, highway, airport and wharf, also in construction of wall body
STANDARD SIZES (4,800mm X 2,400mm) | ||||||||||||
| Mesh size [1] | Mesh size [1] | Wire sizes | Wire sizes | Area[2] | Area[2] | Weight [3] | Sheets | Sheet weight (kg) | Sheets per bundle | Square metres per tonne | |
BS Reference | Main | Cross | Main | Cross | Main | Cross | (Kg) |
|
|
|
| |
Square |
|
|
|
|
|
|
|
|
|
|
| |
A 393 | 200mm | 200mm | 10mm | 10mm | 393mm² | 393mm² | 6.16 | 15 | 70.96 | 18 | 162.34 | |
A 252 | 200mm | 200mm | 8mm | 8mm | 252mm² | 252mm² | 3.95 | 22 | 45.50 | 28 | 253.16 | |
A 193 | 200mm | 200mm | 7mm | 7mm | 193mm² | 193mm² | 3.02 | 29 | 34.79 | 34 | 331.13 | |
A 142 | 200mm | 200mm | 6mm | 6mm | 142mm² | 142mm² | 2.22 | 40 | 25.57 | 46 | 450.45 | |
A 98 | 200mm | 200mm | 5mm | 5mm | 98mm² | 98mm² | 1.54 | 57 | 17.74 | 60 | 649.35 | |
Structural |
|
|
|
|
|
|
|
|
|
|
| |
B 1131 | 100mm | 200mm | 12mm | 8mm | 1131mm² | 252mm² | 10.90 | 8 | 125.57 | 10 | 91.74 | |
B 785 | 100mm | 200mm | 10mm | 8mm | 785mm² | 252mm² | 8.14 | 11 | 93.57 | 14 | 122.85 | |
B 503 | 100mm | 200mm | 8mm | 8mm | 503mm² | 252mm² | 5.93 | 15 | 68.31 | 18 | 168.63 | |
B 385 | 100mm | 200mm | 7mm | 7mm | 385mm² | 193mm² | 4.53 | 20 | 52.19 | 24 | 220.75 | |
B 283 | 100mm | 200mm | 6mm | 7mm | 283mm² | 193mm² | 3.73 | 24 | 42.97 | 30 | 268.10 | |
B 196 | 100mm | 200mm | 5mm | 7mm | 196mm² | 193mm² | 3.05 | 29 | 35.14 | 36 | 327.87 | |
