AC Gear Induction Motor 110v/220v

6-200W

Gearmotor

Similar types

1 Phase Induction motor without Gearbox

Single Phase Reversible Motor

Gearmotor with Electromagnetic brake

Speed Control Motor with Speed controller

Linear Type Gearhead motor with Variable Speed

HP

6W 15W 25W 40W 60W 90W 120W 140W 180W 200W

Voltage

1 Phase 110V 220V     3Phase 220V/380V 415V

Motor Force Axis

Cylindrical         or              Pinion Cut

Peripheral Wave no

50/60HZ

Turning Moment

0.8-10.2 KG/CM

Constant speed

1200-1300rpm under 50HZ 1450-1550RPM under 60hz

Pairing Bearing

2GN 3GN 4GN 5GN GU

Insulation Grade

E Class Insulation

Power&Noise

Capacitive Induction Motor shall used for high power output and low noise single Phase motor

Speed control

For 1 phase gear motor, there are various kinds of speed through the US Speed controller

But for 3 phase gearmotor, speed is controlled by Frequency Inverters.

*Instantaneous alternate between normal and reversible for motor equipped with balanced windings and built-in simple brake mechanism

*Thirty minutes of rated operation. Difference between the induction motor and reversible motor;

the later one can instantaneously be reversible. However, rotating magnetic field & reversible momentum for induction motor occuse in reversible direction. In case no reversible shall be made in loading condition.

*Always maintain the load properly; for a non-exciting type electrical magnetic brake loading can be kept normally by the brake whenever the power source is off

*Instantaneous brake: Over-travel in 2-4 cycles only for a single motor;

*More complex, controllable ,instantaneous normal /reversible time,Allowable stop for 6 time per minute( 3 second or more have to kept for each stop)C&B type of motor is applicable on 100tines of stop per minutes if necessary)

*Wede range of variable speed is adjustable by using the speed controller.

*More operational procedure shall be available ,such as ;variable speed selection,normal/reversible.Slower speed reduction etc

* Built-in rpm sensors.Feed-back control,s contant rpm can be abtained even if there is any frequency variabtion
