Home > Products > Ice Flaker Evaporator > Sindeice industrial range ice flaker evaporator 20T/24h

Sindeice industrial range ice flaker evaporator 20T/24h

FOB Price

USD $12,000 - $20,000 / Unit

1 Unit(Min.Order)

Supply Ability 100 Unit / Units per Month
Port Shenzhen Port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Capacity	20T/24h
Place of Origin	Guangdong, China	Brand Name	SINDEICE
Model Number	SDE-20T	Ice Shape	Flake Ice
Voltage	380V/3P/50Hz	Power(W)	120KW
Dimension(LWH)	213018502240mm	Weight	2200kg
Certification	CE	Warranty	18 months
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Sindeice industrial range ice flaker evaporator 20T/24h

Company Information

SHENZHEN SINDEICE SYSTEMS CO., LTD (Sindeice for short) is a professional manufacturer of ice machines, who has a set of research, design, production, installation, sale and after-sales service. We got a number of experienced experts who engaged in refrigeration and ice machine for many years. With the use of best technology of ice machine and innovative solutions, Sindeice manufactures Flake ice machine, Tube ice machine, Block ice machine, Ice flaker evaporator, Containerized ice plant. Daily capacities are available from 300 kg to 100,000 kg.

Sindeice is sticking to the notion of “great virtue,social commitment”, and the management policy of “integrity, diligence, innovation and mutual benefit”.Sindeice strives to enter into international market.

Product Description

Characteristics of Flake Ice

A mechanical freezing system, however advanced it is, can provide only a low temperature, while cannot provide a humid environment. This disadvantage will dry the surface of, dewater or frostbite the fresh and live commodities. Only ice will provide a perfect cooling and watery environment to keep the fresh and live commodities in an ideal status. Flake ice is widely used in seafood and fresh meat preservation and display in supermarkets. As flake ice is dry and smooth, it will not scratch the fresh and live commodities, in the same time, it will maintain good ventilation. That will ensure the original taste of the commodities and prevent loss caused by dewatering of the commodities.

Large contacting area and quick freezing

As flake ice is in a flat shape, it has a large contacting area compared to ice of the other types. The larger the contacting area, the more effective the freezing becomes. For example, the minimum area of 1000 Kg flake ice is 1,579 square meters, while ice of same quantity in the other types provides only 395 to 1294 square meters contacting area. So the freezing (cooling) effectiveness of flake ice will be 2 – 5 times that of tube ice or cube ice.

Outstanding Food Preservation

Flake ice is dry, soft and flat. These characteristics will protect the packaged food during the packing and refrigeration process. Its flat pattern will minimize the possibility of damaging the refrigerated commodities.

Complete Mixing

As flake ice has a gigantic contacting area and the heat ejection happens quickly, flake ice melts quickly into water, taking the heat away and intensifying humidity of the mixture.

Ice Flaker Evaporator

As the key part of the complete flake ice machine, the ice flaker evaporator plays an important role in making ice. To match the various ice flaker evaporator, you can make different choice about the refrigeration units in different refrigerant (R22, R404a or R717) by yourselves. Before place the order, please let us know which refrigerant you will choose.

Characteristics

1. The ice flaker evaporator use high quality alloy material. Precision welding and surface treatment makes high heat conduction efficient, high strength, longer lifespan.

2. The internally- scraping ice-making mode has been adopted. Under this mode, ice blades scrape ice on the inner wall of the evaporator while the evaporator itself does not move. It reduces the loss of energy as much as possible, guarantees the normal supply of cooling agent as well lower the probability of cooling agent leakage.

3. The stainless steel ice scraper formed without weld. Even by long time scraping, the scrapper keeps still tough, and the ice dropped is sizable with nearly no powder.

Technical Data

*The technical data based on 25℃ ambient temp.18℃ water inlet temp.

*The evaporating temperature is -20℃.

*The condensing temperature is 40℃.

*Power supply: 3P / 380V / 50HZ 3P/220V/60HZ

*Refrigerant:R404a/R22/R507/R717

*Inner wall material: SUS304&Q345 Hard chromium plating

Model	SDE-20T
Daily Output (TPD)	20
Cooling Capacity (KW)	130
Reducer Power (KW)	0.75
Water Pipe	1/2"
Weight (KG)	1970
Dimension (mm)	216016502100

Component

Maintenance

To lengthen the lifetime of an ice machine and increase the efficiency for energy-saving purpose, a regular check on the ice machine is quite necessary. User is suggested to make a monthly/quarterly/yearly record of maintenance and servicing and a very detailed log of the damage servicing so that servicing personnel can properly trace the failure history during trouble shooting process.

Daily Maintenance

Start and Stop the machine as instructed in this manual;

Make a regular record of the parameters in operation daily;

Regular check on the Dryer Filter is necessary. If frost is found on the outlet of the Filter, that may mean jamming inside the Filter. This symptom is normally accompanied by low evaporating pressure and higher condensing water temperature.

Check if the refrigeration oil is normal. If there is lack of refrigeration oil, add more. And if the oil is dirty and goes bad, change it and clean the oil filter and change to a new filter core.

When there is lack of refrigerant, to prevent frequent turn-off of the machine, the capacity status should be set to a partial load. After refrigerant is filled, set the capacity status to full load.

Any failure occurrence should not go unnoticed. A thorough analysis should be done for the cause of failure. Make a thorough analysis of the failure may help with finding a solution to the problem. And notice the SINDEICE after-sale service department of the analysis that is done.

Regular Maintenance

Regular maintenance includes maintenance on a weekly/monthly/quarterly/yearly basis. User can refer to the following scientific maintenance scheme and carry it out in a strict manner. That may help with prevention of failures in a substantially crucial way.

Weekly maintenance

Check and make an analysis of the parameters of ice machine in operation.

Monthly maintenance

Check and make an analysis of the record of parameters of ice machine in operation;

Check the bolts fastening the power wires are always tight;

Check and confirm there is no noise on all moving parts of the ice machine, and there is no abnormality in operation;

Check the water system is working properly;

Check the Compressor’s oil heater is working properly;

Check the High & Low Pressure is normal;

Check the operation current of compressors and motors is normal; check the resistance is normal. If the resistance is lower than 5 MΩ, stop the machine immediately.

Check the water tank/freezing surface/ice storage bin/water distributing tubes/condenser’s fins regularly and clean the dust and dirty things.

Packaging & Shipping

Our Services

Installation:

1). Installing by the user: we will tested and install well the machine before shipment, all necessary spare parts and operation manual are provided to guide the installation.

2). Installing by SINDEICE engineers:

(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer.

(2) Before our engineer arrived in your site, the installation place, electricity, water and installation tools should be ready. Meanwhile, we will provide you a Tool List with the machine when delivery.

FAQ

Q1: What are the payment terms?

A: We usually accept payment by T/T, L/C.

Normally, we accept 30% Deposit and 70% balance paid before delivery.

Q2 : Can any of the products be custom imprinted?

A: If you need to print your company logo on the products and that is available to be custom. Or if you have your own designed idea and that will be our honor to ustomize for you.

Q3: How to ensure that I received the machine undamaged?

A: At first , our package is standard for shipping, before packing, we will confirm product undamaged, otherwise, please contact within 2days. Because we've bought insurance for you, we or shipping company will be responsible!

Q4: Do I need to install the ice machine by myself?

A: For small ice machine, we ship it as a whole unit. So you just need to prepare power and water to run the machine.

For some larger ice machine plant, we need to keep some components seperate for shipping convenience. But no worris about that. An installation brochure will be sent to you,it's very to install the machine.

Q5:What is the warranty for flake ice machine?

A: 18 months after B/L date. Any failure occurred within this period due to our responsibility, we'll supply you the spare parts for free and permanent technical support &consultation all life long for our flake ice machines.
