Home > Products > Metal Ventilation Fan > Metal Circular Duct Exhaust Ventilating Air Blower Fan
Metal Circular Duct Exhaust Ventilating Air Blower Fan
- FOB NINGBO
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | HCSINO | |
| Model Number | HCGF-S2 | Certification | CE, UL |
Product Description
Specifications
Metal circular duct fan1.pefect design
2.Noiseless & power saving
3.Thermally protected AC motor
4.Include mounting bracket
Metal Circular Duct Exhaust Ventilating Air Blower Fan
Housing Material: metal steel
Colour available: Black, White
It is used to transmit and strengthen the air flow inside a network of ventilation ducts.
The Plastic Inline Duct Fan is equipped with ball bearing and visible propeller with a protective grate. The installations can be mounted horizontally and vertically.
The propeller blades are directed backwards, ensuring higher pressure and work effciency.
The casing is made from Plastic (ABS) and the fan sat included fixings for a secure installation.
Accessories: It is possible to connect a variable speed controller, Providing the customer with variable airflow setting.
Specific parameter
Model | Voltage | Frequence | Power | Rotate Speed | Air Volume | Whole Pressure |
(HCGF-S2) | (V) | (HZ) | (W) | (r/min) | (m3/h) | (Pa) |
Φ100mm | 120 / 230 | 60 / 50 | 68 | 2447 | 310 | 340 |
Φ125mm | 120 / 230 | 60 / 50 | 70 | 2340 | 390 | 360 |
Φ150mm | 120 / 230 | 60 / 50 | 97 | 2450 | 610 | 390 |
Φ160mm | 120 / 230 | 60 / 50 | 125 | 2620 | 690 | 420 |
Φ200mm | 120 / 230 | 60 / 50 | 145 | 2548 | 1100 | 590 |
Φ250mm | 120 / 230 | 60 / 50 | 158 | 2440 | 1200 | 560 |
Φ305mm | 120 / 230 | 60 / 50 | 215 | 2410 | 1850 | 670 |
Φ315mm | 120 / 230 | 60 / 50 | 230 | 2373 | 1900 | 690 |
Fan speed controller for choose
