PG - NZ type labyrinth drip irrigation belt anti-clogging test rig
- DALIAN
You May Like
-
SL-SFJ-A type non-contact water supply equipment test bed
-
SG Plastic pipe pressure measuring instrument
-
WQKF-2521 external thermal insulation system of anti wind pressure detection device
-
MBP Fire extinguishers hydrostatic burst test machine
-
DSL-RS-A type Wire and cable vertical burning test instrument
-
FJPG - 4035 type fan coil thermal performance testing device
Product Details
| Place of Origin | Liaoning, China | Brand Name | ZIWEI | |
| Model Number | PG - NZ | Power | Hydraulic | |
| Usage | Drop Tester |
Product Description
PG - NZ type labyrinth drip irrigation belt anti-clogging test rig
[Testing items]Suitable for irrigation with anti-clogging performance test
[Applicable standards]GB/T19812.1-2005 Plastic equipment for water saving irrigation--Part 1:Drip tape with labyrinth on one side
[Technical parameters]
Test range and accuracy: Pressure Range: 0 ~ 0.5 Mpa
Accuracy: 0.5% F.S, Resolution: 0.1 Mpa
Electronic weighing: 500g, 0.001g accuracy
Water temperature 23 ± 2 ℃, Accuracy: 0.5
Synchronous test circuit: 3-way, the biggest drop hole spacing 300mm
Two vertical stainless steel tanks, the effective volume is 6 t
Computer control, the system automatically calculates the results
Power Configuration: AC380V, power 10 kW, three-phase five-wire system
Weight: 3t, after impounding 13t
Test Bench Length: 40m
[Features]
The entire device using computer control, data acquisition control, test automation, test data and reports computer output, convenient and high-precision test, all parts in contact with water made of stainless steel, beautiful and durable, high-quality expression. This device is ideal for domestic projects to carry out such testing.
Package and shipment

CERTIFICATION
OUR CIVIL AND INTERNATIONAL CUSTOMERS :
Cooperated with China Academy of Launch Vehicle Technology (CALT):
