KS-25T Small Plastic Moulding Machine
Negotiable
/ Set
1 Set(Min. Order)
- Shenzhen
- T/T Money Gram Credit Card
You May Like
-
2015 NEW KS-120T Vertical Injection Moulding Machine for Baby Nipples Making
-
KS-85T-D 60 Ton Plastic Injection Machine
-
KS-85T-D Insert Moulding Machine for Eyeglasses
-
KS-85T-D En+plastique+machine+de+moulage+par+injection+caisse
-
KS-85T-D Injection Molding Machine Price
-
KS-85T-D Plastic Injection Molding Machine Low Price
Product Details
| Condition | New | Type | Other, injection molding | |
| Style | Vertical | Brand Name | Kasun | |
| Model Number | KS-25T | Place of Origin | Guangdong, China | |
| Plastic Type | Thermoplastic | Automatic | Yes | |
| Injection Weight | 47-59g | Injection Rate | 36-45cm3/sec | |
| Clamping Force | 25ton | Opening Stroke | 180mm | |
| Certification | ISO9000 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
KS-25T plastic mould machine
Injection section:
--double guiding rod supporting
--cold start protection
--linear displacement transducer accurately monitor injection position
--heating status indication
Computer-control:
--PLC control
--automatic alarm
--digital memory for mold group
Hydraulic unit:
--Japan YUKEN
Clamping unit:
--fine-element analysis used to design platen
--stable running:human-computer interface
Other parts:
--shot counter and reset function
--malfunction alarm light
--self-diagnostic functioin
--emergency stop buttons placed both front and rear of the machine to easy access
| Model | Unit | KS-25T |
| Screw Diameter | mm | 25 | 28 | |
| Injection Pressure | Kg/cm² | 1814 | 1446 | |
| Theoretical Shot Volume | cm³ | 51.5 | 64.6 | |
| (ps) Max.shot Weight(ps) | G/oz | 47 | 59 | |
| Injection Rate | cm³/sec | 36 | 45 |
| Number of Temperature Control | 3 | |
| Clamping Force | Tons | 25 |
| Opening Force | Tons | 7 |
| Platen Size | mm | 490*360 |
| Distance Between Tie Bare | mm | 315*195 |
| Min.Mold Height | mm | 60/120 |
| Oprening Stroke | mm | 180 |
| Ejector Force | Tons | 1.4 |
| Ejector Stroke | mm | 30 |
| Max.Hydaulic Pressure | Kg/cm² | 140 |
| Pump Output | Liters/min | 37.2 |
| Pump Motor Power | kw/HP | 4/5.5 |
| Barrel Heating Power | kw | 2.9 |
| Machine Weight | Tons | 0.75 |
| Machine Dimensions(L×W×H) | m | 1.26*1.02*2.29 |
| Shipping Measurements(L×W×H) | m | 1.5*1.25*1.8 |
Configuration table
| Oil pressure spares: | ||||||||
| oil pump | Taiwan Hai Teke Hydraulic CO.,LTD. | |||||||
| oil motor | U.S. WHITE Group | |||||||
| electromagnetic selector valve | Japan YUKEN CO.,LTD. | |||||||
| proportional valve | Japan YUKEN CO.,LTD. | |||||||
| semi-closure valve controller | Germany Dr.Rexroth INC. | |||||||
| hydraulic valve | Taiwan Hai Teke Hydraulic CO.,LTD. | |||||||
| Electric spares: | ||||||||
| computer controller | Procheson Technology CO.,LTD. | |||||||
| temperature sensing wire | Taiwan Arico CO.,LTD. | |||||||
| SSR | Taiwan Yangming CO.,LTD. | |||||||
| electric ruler | Switzerland Mrian CO.,LTD. | |||||||
| power switch | Mitsubishi | |||||||
| Others: | ||||||||
| electronic motor | Global Electric Machinery LTD. | |||||||
| sealing | Japan NOK Joint-Stock-Cooperation | |||||||
| feed pipe group | Taiwan Tianxing CO.,LTD. | |||||||
| tie bar | Taiwan Jiangjun Machinery CO. | |||||||
| oil pipe | Italy ALFA CO. | |||||||
| oil cylinder | Taiwan Jiangjun Machinery CO. | |||||||
