WELLINE high efficiency shaking table gold ore processing line

Condition	New		Type	Gravity Separator
Production Capacity	0.8-1.5 t/h		Place of Origin	Henan, China
Brand Name	WELLINE Gold mining machinery		Model Number	6-S gold mining equipment
Voltage	380V		Power(W)	1.1KW
Dimension(L*W*H)	4450*1850*800mm		Weight	800KG
Certification	ISO9001:2008 ,BV		Warranty	yes
After-sales Service Provided	Engineers available to service machinery overseas

Specifications

gold ore mining line:
-max.feed size 2mm
-capacity30-60t/d
-for coarse fine sand,slurry
-FRP surface,corrosion resist

High Recovery Rate 6-S series Gold Mining equipment,WELLINE Make Good performance Gold Shaking table



Shaking table

Our shaking table is a piece of gravity separation equipment for fine materials.This equipment is widely used in separation of tin,tungsten,gold,silver,lead,zinc,tantalum,niobium,iron,manganese,ferrotitanium and coal.Our company has long history of shaking table production and we provide a variety of shaking tables with high pricessing capacity,high recovery rate and high enrichment ratio.



Structure

Our shaking table consists of the bed,motor,ore trough,water trough,slope adjustment device,lubrication system,etc.



Advantages of 6-S gold mining equipment

6- S Gold shaking table is one of the main equipment of gravity concentration , it is widely used in the selection of tungsten, tin , tantalum, niobium and other rare metals and precious metal ore . Roughing, selected scavenger can be used for different operations ,separating coarse ore ( 2- 0.5mm) , fine sand ( 0.5 - 0.074mm ), slime ( -0.074mm ), different grain size . Can also be used to choose the iron, manganese ore and coal . When dealing with other minerals such as tungsten , tin , table effective recycling granularity range of 2-0.22 mm.



Technical Parameters of 6-S Gold Mining equipment

Name		Coarse sand surface of table	Fine sand surface of table	Ore slime surface of table
Dimension	Length (mm)	4450	4450	4450
	Transmission end width (mm)	1855	1855	1855
	crude ore width (mm)	1546	1546	1546
Max. feeding size (mm)		2	0.5	0.15
Feed amount (t/h)		30-60	10-20	15-25
Feed density (%)		25-30	20-25	15-25
Stroke (mm)		16-22	11-16	8-16
Frequency ( f)		45-48	48-53	50-57
Water quantity added(t/h)		80-150	30-60	10-17
Horizontal obliquity (°)		2°30′-4°30′	1°30′-3°30′	1°-2°
Longitudinal obliquity (%)		1.4	0.92	--
Dressing Area (m2)		7.6	7.6	7.6
Cross-section Shape of table		Rectangular	Saw tooth	triangle
Motor Power (kw)		1.1	1.1	1.1
Transmission Mechanism		Eccentric linkage

Remark:Any changes of Gold mining equipment shall not be advised additionally.



More pictures details about our Gold shaking table equipment for Gold mining



As one of the largest chinese professional Gold mining equipments manufacturers and suppliers,Zhengzhou Future Machinery Company provides high quality and large capacity of products at lower price to our customers.

Warmly welcome your sincere inquiry and cooperation!
