PVC laminated ceiling design

       Atlantis superior PVC laminated gypsum ceiling board adopts Atlantis paper-faced gypsum board as the base board, and imported good quality latex painting, polythere compound pellicle, aluminum foil as the surface veneer material, through a gigh technological manufacturing process. It has characteristics of safe, environmental, healthy, non-dust, noxious-free, moisture-proof, sunken proof, and easy clean. It is a economical, elegant, fashionable, ceiling decorative material. This superior material is mainly used in the indoor decoration for super class buildings such as hotels, restaurants, shopping malls theaters, danceries, cinemas, stations, auditoriums, offices, sitting rooms, business buildings, precision apparatus rooms and industral or residential buildings.

* Material: Atlantis paper-faced gypsum board

* Thickness: 7mm, 7.5mm, 8.0mm, 8.5mm, 9.0mm, 9.5mm, 12mm, 12.5mm

* Sizes: 595x595mm, 600x600mm, 595x1195mm, 603x603mm, 605x605mm,603x1212mm, 610x1220mm(2’x 4’)

* Size tolerance: length<±2mm, width<±2mm, thickness<±0.5mm

* Weight:7mm=5.5kg/sqm, 7.5mm=5.7kg/sqm, 8.0mm=5.9kg/sqm, 8.5mm=6.2kg/sqm, 9mm=6.8kg/sqm, 9.5mm=7.1kg/sqm, 12mm=9.2kg/sqm, 12.5mm=9.5kg./sqm

* Strength: >160N

* Characters: non-flammable B1, in accordance with Chinese standard GB8624-1997

* Installation: match with ceiling T-bar

* Packing: Export carton( 8pcs or 10pcs carton with PE plastic film)
