YD Series Electric Motor 2speed

FOB Price

US$ 20 - 3,000 / Set

5 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	NULANG	Model Number	YD
Type	Asynchronous Motor	Frequency	50HZ/60HZ
Output Power	0.45/0.55KW	Protect Feature	Other, Totally Enclosed,Waterproof
Phase	Three-phase	Certification	CCC, CE, ROHS, Other, CCC, CE, ROHS, ISO9001:2008
AC Voltage	Other, 380V	Place of Origin	Zhejiang, China
Efficiency	IE 1

Specifications:

1) Frame size: 80

2) Rated Power: 0.45/0.55KW

3) Rated voltage: 380V

4) Frequency: 50 Hz

5) Protection class: IP44, IP54, IP55

6) Insulation class: E, B, F

7) Material: cast iron / aluminum

8) EFF: EFF2

9) Poles: 4

10) Cooling method: IC411 (total-enclosed fan-cooled type)

11) Mounting type: IMB3, IMB35, IMB5, IMB14, IMB34.

12) Operating mode: S1

13) Ambient temperature:-15^oC<θ<40^oC

14) Altitude: altitude should be lower than 1,000m above the sea level

15) Relative humidity: not higher than 90%

16) Special motor can be designed according to the customer's requirement

17)Packing:Foam box

Certificate:
