Home > Products > 2. Water Filling Machine > Pure Water Filling Machine/Pure Water Filling produce line
Pure Water Filling Machine/Pure Water Filling produce line
- ShangHai port for Pure Water Filling Machine/Pure Water Filling produce line
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | Beverage, Other, Beverage, Pure Water Filling Machine/Pure Water Filling produce line | |
| Packaging Type | Bottles, Other, Bottles, Pure Water Filling Machine/Pure Water Filling produce line | Packaging Material | Wood, Other, Wood, Pure Water Filling Machine/Pure Water Filling produce line | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380V | Power | 2.2KW, 2.2KW | |
| Place of Origin | Jiangsu, China | Brand Name | OK | |
| Model Number | CGF24-24-8 | Dimension(L*W*H) | 2500X2100X2300MM | |
| Weight | 2100KG | Certification | CE, CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Pure Water Filling Machine/Pure Water Filling produce line
Machine Feature:
1)the machine can carry out the three functions of bottle washing , filling , capping.
2)the advanced programmed controller (PLC) is adopted to control the machine running automatically.
3)the bottle entry section adopts air conveyor system.
4)the bottle exit section adopts belt conveyor system,which can adjust the speed.
5)the machine are high quality,the key spare-parts are made buy famous producer.
Technical Parameters:
Model | CGF16-12-6 | CGF18-18-6 | CGF24-24-8 | CGF32-32-10 | CGF40-40-12 | CGF50-50-15 | |
washing/filling / capping heads | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-10 | 40-40-12 | 50-50-15 | |
production capacity(b/h) (for 500ml) | 4500 | 7500 | 10000 | 15000 | 20000 | 24000 | |
Punch pressure(kg/cm2) | 2~3 | ||||||
power(kw) | 4.30kw | 5.05kw | 6.55kw | 8.65kw | 9.65kw | 10.70kw | |
size(mm) | 2200x1550 x2700 | 2500x2020 x2700 | 3100x2200 | 4100x2550 | 4600x2950 | 5450x3450 | |
weight(kg) | 2500 | 3500 | 5500 | 7500 | 9800 | 11600 | |
photos for pure water filling machine
factory for pure water filling machine
