Home > Products > Shale Gas Genset > Power Plant Jinan Engine 500kw Shale Gas Generator
Power Plant Jinan Engine 500kw Shale Gas Generator
US$ 620,000 - 666,000
/ Set
1 Set(Min. Order)
- qingdao
- T/T Credit Card
You May Like
-
2016 Hot Sale 500kw Shale Gas Generator for Sale
-
AC Three Phase Output Type 500kva Shale Gas Generator
-
400kw Methane Fuel Shale Gas Generator
-
Methane Gas Powered Engine Natural Gas 20kw-600kw Shale Gas Generator Set
-
CE Certified 10kw - 1mw Coal Methane Gas /shale Gas Generator Set
-
CE Certified 10kw - 1mw Methane Coal Gas Generator /shale Gas Generator for Sale
Product Details
| Place of Origin | Shandong, China | Brand Name | LVHUAN | |
| Model Number | LHSG500 | Output Type | AC Three Phase | |
| Speed | 1000r/min | Frequency | 50Hz | |
| Rated Power | 500kw | Rated Voltage | 400/230v | |
| Rated Current | 910A . |
Product Description
power plant jinan engine 500kw shale gas generator
1. Technical Specs and Technical Performance of Shale gas Generator set
Model Number | LHSG500 |
| Brand Name | LVHUAN |
| Rated Power/prime power | 500 Kva/400kw |
| Rated Speed | 1000 rpm |
| Rated Frequency | 50 Hz |
| Rated Voltage | 400/230V |
| Phase | AC 3 phase 4 wire |
| Starting system | 24V DC electric motor |
| Cooling method | water cooler |
| Lubricant method | passive and splash |
| Isolation class | H |
| Protection | IP23 |
| Power Factor | 0.8 lagging |
| Exciting method | Brushless |
| Voltage Stability | ≤±2% |
| Voltage Transient | ≤±10% |
| Voltage Stable time | ≤1 s |
2. Technical Specs of Gas Engine
| Engine Capacity | 71.4 L |
| Cylinder Number | 12 |
| Cylinder Diameter | 190mm |
| Range | 210mm |
| Heat consumption | ≤9.8mj/kw.h |
| Oil consumption | ≤1.1g/kw.h |
3. Other Specification
| Color | your choice |
| Certificates | ISO 9001:2008, ISO 14001-2008, CE |
| Warranty | 1 year or 1500 running hours, which occurs firstly |
| Type | Open |
| Control System | Automatic alarm system |
