FMRS40 Rotation pulverized coal burner

FMRS40 Pulverized coal combustion device configuration and parameters

1,constitute:                                                                                FMR40Pulverized coal combustion device by rotary furnace(model number:LT40)coal pulverizer(model number:FMJ40)   Fuel firing system(model number:RY15)   electrical apparatus control systemquadruple ; Made up of four parts.

2,Main Parameter:

(1)Furnace:

    fan type:4-72No.4A      Power of fan:2.2kW      Coal:500kg/h

    characteristic:double intakes ; two intakes  high collection effciency

                     open-back  Furnace  The oven heated evenly  Easy to clean up the slagging in the hearth

                     External instruction in crater  Ignition convenient

(2)coal pulverizer:

   enter coal particle size:<25mm        come coal particle size:≤200mesh

   The rated output: 500kg/h      motor power:22 kW

   To the coal and electric power:1.5 kW

characteristic:Feed stepless frequency control of motor speed

                 Multi-stage crushing, fine pulverized coal

                 High pressure centrifugal spray, spray distance far

                 Alloy steel blade, long service life

(3)Fuel firing system:pump power  0.75KW

(4)Conveying pipe:Pipe diameter 160mm

3,The quality requirement

Fixed carbon content > 60%     Calorific value > 5500 kcal/kg      Volatile content > 20%

Water content < 2%      Ash content < 8%       Sulfur content < 1%

4,Equipment technical indicators

Production capacity: 500 kg/h operation mode: manual
Total power: 30 kw maximum motor power: 22 kw
The weight: 4 t
Overall dimension: length x width x height: 7 * 2 * 1.5 m3
