Home > Products > Diesel generator set > Open Type 350KVA (280kw) Diesel Generator Set With Perkins Engine.
Open Type 350KVA (280kw) Diesel Generator Set With Perkins Engine.
US$ 34,546 - 39,728
/ Set
1 Set(Min. Order)
- GUANGZHOU SHENZHEN
- T/T
You May Like
-
Perminent Reliable 1500kva(1200kw)diesel Generator With Engine(4012-46TWG2A )
-
High Economical Efficiency 500KVA (400kw) Diesel Generator Set With Perkins Engine(2506A-E15TAG2)
-
Globle Guaranteed Service for 650kva(520kw)with Perkins Engine (2806A-E18TAG2)
-
High- Performance 1710kva(1368kw)diesel Generator With Perkins Engine(4012-46TAG3A )
-
Imported Famous Brand 1710kva(1368kw)silent Diesel Generator With Perkins Engine(4012-46TAG3A )
-
Large Power Import 1850kva(1480kw)diesel Generator With Perkins Engine(4016TAG1A )
Product Details
| Place of Origin | Guangdong, China | Brand Name | YLFDJ | |
| Model Number | 1103A-33TG2 | Output Type | AC Three Phase | |
| Speed | 1500rpm/1800rpm | Frequency | 50hz/60hz | |
| Rated Power | 280kw/350kva | Rated Voltage | 400/230V/110V | |
| Rated Current | 504A |
Product Description
| Genset Model | YLGF-280 | |||||
| Genset | Power Capacity (kw/kva) | 280/360 | ||||
| Rated Voltage (V) | 400/230/110 | |||||
| Rated Current (A) | 504 | |||||
| Rated Frequency (Hz) | 50/60 | |||||
| Rated Speed (rpm) | 1500/1800 | |||||
| Power Factor / Phase | Cos 0.8 Lagging, 3 phase | |||||
| Cooling System | Closed cycle water-cooled with fan,water tank | |||||
| Overall Dimension (L×W×H) (mm) | 3500x1150x 2000 | |||||
| Gross Weight (kg) | 3450 | |||||
| Engine Brand | Perkins | |||||
| Diesel Engine | Engine Model | 2206A-E13TAG2 | ||||
| Prime Power (kw) | 280/360 | |||||
| Engine Structure | 6Cylinder,Vertical,Inline,4 stroke | |||||
| Bore×Stroke (mm) | 105x127 | |||||
| Displacement (L) | 3.3 | |||||
| Compression Ratio | 17.25:1 | |||||
| Lube Capacity (L) | 7.9 | |||||
| Fuel System | PT type fuel injection pump | |||||
| Fuel Consumption (g/kw.h) | 209 | |||||
| Lube Consumption (g/kw.h) | 2.2 | |||||
| Rotating Speed (rpm) | 1500/1800 | |||||
| Speed Governing | electric speed governor | |||||
| Starting Method | By 12V batteries | |||||
| Alternator Brand | YLFDJ | |||||
| Alternator | Alternator Model | YLW-280 | ||||
| Insulation Class | Class H | |||||
| Steady Voltage Regulation | ≤ +/- 0.5% | |||||
| Instant Voltage Ragulation | -15%~+20% | |||||
| Voltage Fluctuation Rate | ≤ +/- 0.5% | |||||
| Steady Frequency Regulation | ≤ +/- 0.5% | |||||
| Instant Frequency Ragulation | -7%~+10% | |||||
| Phase/Connection Type | 3 phase 4 wire/Y type | |||||
| Controller | Controller Brand | ZZ6110 | ||||
Payment & Delivery Terms
1.Minimum Order Quantity: 1 set.
2.Packing Details: standard export packing.
3.Delivery Time: 30 working days after receipt of deposit or original L/C.
4.Payment Terms: T/T (30% as deposit,the balance to be paid before delivery) or L/C.
5.Valid time of the quotation: 30 days.
Attachment list
1.Fuel connecting pipes
2.12V DC battery c/w battery cables 2 sets
3.Industrial type silencer c/w stainless steel flexible exhaust bellows
4.Shock absorption rubbers 4 pcs
5.The tool kit and 1 set of manuals (English version).
