Truck-mounted Concrete Pump 37m SHACMAN

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port qingdao shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Diesel
Place of Origin	Shandong, China	Brand Name	shantui
Model Number	HJC5160THB 26M	Weight	16t
Dimension(LWH)	958824903688	Certification	ISO
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

truck monted concrete pump truck concrete pump truck
1. Engine Cummins 254kw
2. Range 26-56m
3. Pump system Mitsu

Truck-mounted concrete pump 45m

Specifications

Model			Unit	HJC5320THB-45	HJC5330THB-45	HJC5331THB-45
Overall specifications	L×W×H		mm	12000×2500×4000	12000×2500×4000	12000×2500×4000
	Gross weight		Kg	32300	33000	33000
Boom	Folding style			5“RZ”
	Articulations			90/180/180/250/180
	Vertical reach		m	45
	Horizontal reach		m	41
	Reach depth		m	28
	Unfolding reach		m	9.6
	Rotation			365°
	End hose length		m	3
	Hydraulic system pressure		MPa	35
Outrigger	Folding style			“X”
	spread L-R front		m	9.23
	Spread L-R rear		m	9.99
Pumping specification	Theoretical concrete displacement	High pressure	m3/h
		Low pressure	m3/h	120
	Theoretical pumping pressure	High pressure	MPa
		Low pressure	MPa	7
	Delivery cylinder bore		mm	230
	Delivery cylinder stroke		mm	2000
	Hopper capacity		L	600
	Slump scope		cm	14~23
	Max. aggregate size		mm	40
	System pressure		MPa	32
Power system	Transfer case			Germany Stiebel
	Master pump			Germany Rexroth
	Boom/outrigger pump			Germany Rexroth
Water pump	Drive mode			Hydraulic drive
	displacement		L/min	20
Others	Remote controller			Germany HBC
	Water tank capacity		L	300
	Oil tank capacity		L	740
	Hydraulic oil cooling method			Air cooled
	Lubrication method			Automatic hydraulic lubrication

Company Information

SHANTUI Concrete Pump Trucks for construction company
While Chutian is an older established brand, Shantui immediately began to implement its superior manufacturing processes and know-how to the Chutian production lines. The result is a company that is now poised to take over the 3th position in China’s vast market. The combination of Chutian’s 20-year experience in concrete machinery and Shantui’s mature QC and parts and service network, appears to be a winner.
Shantui concrete truck mixers come with planetary gearbox transmissions for smooth shifting, strong wide frames for increased stability and low centers of gravity,and reinforced front and rear axle suspension systems for safety and maneuverability. They have excellent visibility and spacious, ergonomically designed cabs.
