LTEC600V hospital portable Veterinary Medical Anesthesia Device CE Approved

Specifications

Specification of LTEC600V hospital portable Veterinary Medical Anesthesia Device  :

Application: 0.5~100Gkg animal

Ventilation mode: Closed, half-closed, half-open

Tidal volume( Manual Mode): 10~2000ml

Gas pressure: 0.25~0.65Mpa

Flow meter: Oxygen two tube: one tube:0.1~1,one tube:1~10L/M

APL valve: 0.5~6.0Kpa

OXYGEN Flush: 25~75L/min

I:E: As the doctor operation

BPM: As the doctor operation

Monitoring:  Airway pressure, respiratory mode.

Three gauges: One for Oxygen source pressure

One for oxygen working pressure

One for airway pressure

Vaporizer
With the latest innovative design of delivery system, vaporizers deliver accurate concentration under varying conditions of variable flow rate, pressure, temperature and so on.
Stably deliver agent, automatic temperature-compensating, deliver accurate agent
Sophisticated delivery system,Stable, prompt, accurate
Various kinds of mounting types.

Safety lock device to prevent the anesthetic gas volatile accidentally.

The big view window is convenient to observe drug usage levels.

Specification
Concentration range:
Enflurane 0.2 to 5%
Isoflurane 0.2 to 5%
Halothane 0.2 to 5%
Sevoflurane 0.2 to 8%

Flow range:0.2 to 15L/min
0.2 to 10L/min(normal usage)for concentrations>5 vol%
Filling volume for agent:
About 340ml with dry wick
About 300 ml with moist wick

Mounting type:
selectatec compatible
draeger plug in
cage mount(ISO 23mm tapers)
cage mount with interlock

Net Weight: 26kg

Gross Weight: 30kg

Size:86 X51 X 38CM

Who we are ?

Our Leyte Electronic Co., Limited is a leading exporter and supply chain service provider for      LTEC600V hospital portable Veterinary Medical Anesthesia Device

Our main products include X-ray machine, B ultrasound scanners, ECG, patient monitor, ICU equipment, Lab equipment, and other related medical disposables.

We have exported to more than 50 countries and built long term partnerships with clients of     LTEC600V hospital portable Veterinary Medical Anesthesia Device

Trade Term

1.  This offer is valid with 30 days.

2.  Delivery time: In 10 days after receive the payment

3.  Item of payment: T/T ,LC,Western Union ,Escrow ,Paypal total payment before delivery

4.  Carton box

Delivery detail:
1.We ship goods by UPS/DHL/FEDEX/TNT express takes 3~ 5 days to arrive , which is door to door ,you no need go out can get  LTEC600V hospital portable Veterinary Medical Anesthesia Device

2.We can also help you ship by air cargo, it takes about 2-7 days to arrive, while you need to go to Air port to take LTEC600V hospital portable Veterinary Medical Anesthesia Device

3.If goods are large quantity and you need not so urgently ,you can choose by sea to save some freight cost which takes you about one month to get  LTEC600V hospital portable Veterinary Medical Anesthesia Device

No matter what delivery way ,depending on your actual requirements.
Our services:
1. For all your inquires about us or our LTEC600V hospital portable Veterinary Medical Anesthesia Device  , we will reply you in detail within 24 hours
2. We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language
3. We offer OEM services. Can print your own logo on LTEC600V hospital portable Veterinary Medical Anesthesia Device , can customize the retail box packing and other things.
4. We have very experienced engineers ,can help you better use  LTEC600V hospital portable Veterinary Medical Anesthesia Device

Our contact details:

We got several kinds of communicate ways, just hope to keep good touch with you
