2 Years Warranty Fiber Color Laser Marking Machine
- Wuhan/Shenzhen/Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Wholesale Price Titanium Laser Engraving Machine
-
Copper Desktop Laser Marker Fiber Laser Marking Machine
-
50W Stainless Steel Fiber Laser Marking Machine Laser Marker
-
2015 Hot Sale Metal and Non-Metal Fiber Laser Engraving Machine
-
20W Fiber Laser Engraving Machine for Engraving Pens
-
30W Fiber Laser Engraving Machine for Engraving Metallic
Product Details
| Condition | New | Laser Type | Fiber Laser | |
| CNC or Not | Yes | Cooling Mode | Air Cooling | |
| Control Software | EZCAD | Graphic Format Supported | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | |
| Working Accuracy | 0.01mm | Place of Origin | Hubei, China | |
| Brand Name | Keyi | Model Number | KY-M-FB10/20/50 | |
| Power(W) | 10W/20W/50W | Certification | CE, Other, CE, FDA | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
2 Years Warranty Fiber Color Laser Marking Machine
Product Description
1. Compactness: With the unique all built-in integration design, the optical, electronic and mechanical components are highly integrated, so that the whole machine weighs only 16kg. It can be called the smallest fiber laser marker in the world. In addition, it adopts imported fiber laser, and coupled with all air-cooled design, it need not external cooling devices.
2. High Durability: The laser module has a long service life (greater than 100,000 hours; while the traditional lamp pump YAG can only serve hundreds of hours and the semiconductor can serve 20,000 hours or so).
3. Low consumption: Due to the all air-cooled design, no consumable materials and free of maintenance, it has a low cost at use. Furthermore, it saves energy with a total power of 200W.
4. High speed: It applies imported high-speed galvanometer scanning head, which has greatly reduced the latency and increased the marking speed, which is 3 to 10 times of the first generation of traditional lamp-pumped marker and the second-generation of semiconductor marker (depend on the marking material).
Characteristic
1. Fiber lasers with high photoelectric conversion efficiency
2. Air cooled and low power consumption less than 0.5Kw
3. Good laser beam quality M2<1.2
4. Free maintenance and lifetime can be more than 20000 hours.
5. Compact design and can combine with flying marking or pocket design.
Parameter
| Product Name | FB serial portable laser marking machine | |
| Marking Parameters | FB serial portable laser marking machine(20W) KYD-FB | 110mm*110mm(Any other else) |
| Marking Speed | 0-7000mm/s | |
| Marking depth /Roman Type ,Character Height 1mm | 0.01-0.5mm(Depending on the material ) | |
| Marking Content/Character Types | Text/letters/numbers/symbols/graphics/design/logo, etc. Date/time/QR code / Barcode/ batch number/serial number, etc. real-time number coding | |
| Min. Spot Size | 0.02mm | |
| Marking Width | 0.01-0.2mm(Depending on the material) | |
| Repeatability | ±0.003mm | |
| Laser Characteristics | Laser Type | Fiber Laser/1064nm |
| /Wavelength | ||
| Output power(General) | ≥20W | |
| Power Stability(8h) | <±0.01ms | |
| Beam Quality | M2<1.2 | |
| Modulation Frequency | 20-80(KHZ) | |
| Laser Safety Class | ClassIV | |
| Other Info | System Protection Rating | IP54 |
| Cooling | Air Cooling | |
| Operating Environment Requirements | Temp.:8℃-40℃; Relative humidity≤0.95RH; Air dust≤0.01g/m³;Atmospheric pressure ≤86—106Kpa | |
| Power Supply | 220V±5% ,50Hz±5% Single-phase AC power supply | |
| Power Consumption | <0.5KW | |
| Overall Dimension (L×W×H) | 700×280×520(mm) | |
| Total Weight | 40(kg) | |
Sample Show
Packing and Shipping
1. Keyi Optic & Electric products packaging are in line with the international air and sea transport packaging standards.
2. With sturdy wooden or iron box packing for long-distance transport, protection against the water and rust and shock and rough handling, for each part of the overall lifting equipment according to standard packaging.
3. Every package has a detailed packing list.
Service Commitment
1, Keyi Optic & Electric provide two years free warranty and life-long maintenance. We provide spare parts and service free during warranty time. After the warranty period shall charge only when maintenance, continue to provide a broad and favorable technical support and spare parts supply.
2, Keyi Optic & Electric will upgrade software free for our products.
3, Keyi Optic & Electric received your repairing call, our after-sales engineers will give a clear answer within one hour, arrived at the scene within 24 hours, to ensure that users do not delay production.
