Home > Products > Battery pack 24V,36V,48V > 8s1p Nominal Voltage 25.6V 45Ah Li-ion Batterie Pack
8s1p Nominal Voltage 25.6V 45Ah Li-ion Batterie Pack
- Shenzhen
- Money Gram Credit Card
You May Like
-
Rechargeable Lifepo4 Batteries 8S1P 24 Volt 45Ah
-
Wholesale 12V 24V 36V 48V 60V 12Ah Battery for Electric Scooter
-
Deep Cycle Rechargeable 48V 36Ah Lithium Iron Phosphate Battery
-
48V 36Ah Battery for Rechargeable Vacuum Cleaner
-
Lifepo4 48 Volt 36Ah Batteries for Bike
-
Deep Cycle Rechargeable Lifepo4 Battery 48V 36Ah for Electric Bicycle
Product Details
| Place of Origin | Guangdong, China | Brand Name | OSN | |
| Model Number | OSN-2445 | Composed Type | Other, 8S1P | |
| Type | Other, Lifepo4 | Components | Other, Lifepo4 | |
| Size | 400*149*171mm | Voltage | 25.6V | |
| Weight | 14.58kg | Nominal Capacity | 45AH | |
| Application | E-Bike, E-Scooter, EV battery |
Product Description
8s1p nominal voltage 25.6V 45Ah li-ion batterie pack
LiFePO4 Battery has long cycle life (up to 2000 cycles) and good availability. Our LiFePo4 Lithium-ion technology utilizes natural, phosphate based material and offers the greatest combination of performance, safety, cost, reliability and environmental characteristics. Moreover we can modify the design of battery packs to provide the best solution to satisfy our customer's needs.
Specification:
Items
| Parameters |
Model | OSN-L45180A-2445 |
Material | Lifepo4 |
Nominal Voltage | 25.6V (3.2V any single cell) |
Nominal Capacity | 45AH |
Cells inside | Lifepo4 45Ah |
Configuration | 8S1P |
BMS inside | BMS-L8S8005-A03 |
Charging Current | · Standard Charging: 9A(0.2C) · Max. Charging:22.5A(0.5C) |
Max. Discharging Current | · Max. Continuous Discharging: 80A · Max. Peak Discharging: 160A |
Cut-off Voltage | · Fully charged: 29.2V (3.65V any single cell) · Charging Cut-off: 31.2V (3.9V any single cell) · Discharging Cut-off: 16V (2V any single cell) |
Dimensions (L*W*H) | 400*149*171mm |
Net Weight | 14.58 kg |
Output Connector |
A pair of 8AWG wire ( Approx. 260mm length ) |
Input Connector
| XLR connector |
Working Temperature | · Charging: 0°C ~50°C · Discharging: -20°C ~60°C |
Storage Temperature | · ≤1month: -10–45°C · ≤3month: 0–30°C · ≤6month: 20±5°C |
Life Cycle | >2000 cycles to 80% with 100% DOD under normal temperature |
Application | motorcycle,e-bike, e-scooter, e-wheelchair, e-golf cart, medical equipment, power tool, electric unicycle etc
|
