50kw/62.5kva Ricardo silent genset lower noise

FOB Price

US$ 3,000 - 500,000 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

silent generator
1.AMF&ATS,canopy is optional
2.20 years production experience
3.Warranty 1500hours or 1 year

Silent genset
1.AMF&ATS,canopy is optional
2.20 years manufacture experience
3.Noise less than70db
4.1 year or 1500hours warranty which is first

Silent genset specifications:

The basic specifications: 230 / 400V AC, 50Hz / 60Hz, 0.8Pf , three phase four wires

Use: can be used for the open type and the soundproof type , automatic type

GENERATOR SET MODEL	KS50GF
Voltage	400V/230V
Frequency	50Hz
Power factor	0.8
Phase	3Ph 4Wr
Prime Output (kW/kVA)	50/62.5
Standby Output(kW/kVA)	55/68.75
TECHNICAL DATA
DIESEL ENGINE MODEL	4105ZD1
Brand	Ricardo
Engine Characters	water-cooled, inline, 4-stroke,direct injection
Constant Output (kW/kVA)	56/70
Standby Output (kW/kVA)	61.6/77
Aspiration	Turbocharged
Bore(mm) X Stroke(mm)	105x125
Piston Speed (m/s)	6.25
Compression Ratio	16:1
Machine Governor	≤5%
Electronic Governor	≤1%
Acostic Pressure(dBA)	≤95
Exhaust Temperature	≤600
Lube Capacity	12
No.of Cylinder	4.L
Displacement	4.33
Rating Fuel Consumption (L/h)	14
ALTERNATOR
Brand	Copy Stamford
Model	TFW2-50
Continuous Output(kW/kVA)	50/62.5
Power Efficiency	87.00%
Excitation Type	Brushless
Insulation Class	H
DIMENSIONS AND WEIGHTS
Dimension(mm)	2000x780x1500
Gross Weight	1030

Thanks for visiting our websit , I f you need , welcome here !
