Home > Products > Marine diesel generator > weichai ricardo best price small diesel silent generator
weichai ricardo best price small diesel silent generator
US$ 500 - 500,000
/ Set
1 Set(Min. Order)
- Qingdao
- T/T
You May Like
-
marine diesel engines generator 4-cylinder engine
-
4100C 4 cylinder outboard diesel engine with gearbox J16A
-
small marine diesel engine R4105C CM33CS gen-set
-
CM40CS 58kw marine engine set with motor R4105ZC
-
15.6kw 2 cylinder 2000rpm 295C marine diesel engine
-
weifang brand 100kw proof generator 10kw alternator
Product Details
| Place of Origin | Shandong, China | Brand Name | Kaisheng | |
| Model Number | Ricardo 24kw diesel generator | Output Type | AC Three Phase | |
| Speed | 1500/1800r/min | Frequency | 50/60Hz | |
| Rated Power | 24kw | Rated Voltage | 230/400 | |
| Rated Current | 43.2A |
Product Description
Specifications
small diesel silent generator1.24kw/30kva,water-cooled
2.with the CE,ISOcertificated
3.Trailer,AMF, ATS,canopy is optional
weichai ricardo best price small diesel silent generator
Silent diesel generator specifications
| GENERATOR SET MODEL | KS24GF | |
| Voltage | 400V/230V | |
| Frequency | 50Hz | |
| Power factor | 0.8 | |
| Phase | 3Ph 4Wr | |
| Prime Output (kW/kVA) | 24/30 | |
| Standby Output(kW/kVA) | 26.4/33 | |
| TECHNICAL DATA | ||
| DIESEL ENGINE MODEL | K4100D | |
| Brand | Ricardo | |
| Engine Characters | water-cooled, inline, 4-stroke,direct injection | |
| Constant Output (kW/kVA) | 30.1/37.6 | |
| Standby Output (kW/kVA) | 33/41.25 | |
| Aspiration | Natural | |
| Bore(mm) X Stroke(mm) | 100x115 | |
| Piston Speed (m/s) | 5.75 | |
| Compression Ratio | 19:1 | |
| Machine Governor | ≤5% | |
| Electronic Governor | ≤1% | |
| Acostic Pressure(dBA) | ≤95 | |
| Exhaust Temperature | ≤540 | |
| Lube Capacity | 9 | |
| No.of Cylinder | 4.L | |
| Displacement | 3.61 | |
| Rating Fuel Consumption (L/h) | 7.74 | |
| ALTERNATOR | ||
| Brand | Copy Stamford | |
| Model | TFW2-24 | |
| Continuous Output(kW/kVA) | 24/30 | |
| Power Efficiency | 83.50% | |
| Excitation Type | Brushless | |
| Insulation Class | H | |
| DIMENSIONS AND WEIGHTS | ||
| Dimension(mm) | 1720x760x1500 | |
| Gross Weight | 860 | |
