Home > Products > Printing Machine > Super Hot Plastic Bag Printing Press/4 Color Plastic Bag Flexo Printing Machine/
Super Hot Plastic Bag Printing Press/4 Color Plastic Bag Flexo Printing Machine/
- Ningbo Shanghai
- T/T Credit Card
You May Like
-
YT-6600 Flexographic Printing Machine Plastic Bag Printing Machine
-
Plastic Bag Printing MachineYT-61000 Flexographic Printing Machine
-
Ruian Huana Multi color Rotogravure Plastic Bag Printing Machine
-
Ruian Huana High Quality Plastic Bag Printing Machine
-
Ruian Huana High Quality Plastic Bag Printing Press
-
High Quality Polythene Bag Printing Machine
Product Details
| Condition | New | Plate Type | Letterpress | |
| Place of Origin | Zhejiang, China | Brand Name | Huana | |
| Model Number | YT-4600 | Usage | Paper Printer | |
| Automatic Grade | Automatic | Voltage | 220v | |
| Gross Power | 11.2KW | Dimensions(L*W*H) | 4300*1900*2500mm | |
| Weight | 2000kg | Certification | BV | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.accurate color register2.easy operation
3. it can print roll plastic film, such as PP,PE,PVC,BOPP
Four colors flexographic printing machine
Feature:
1.1The meter counter can set printing quantity according to the requirements,stop the machine automatically at the quantity or when the material is cut off.
1.2 Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
1.3 The printing ink is spread by the anilox cylinder with even ink color.
1.4 Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.360continuous and adjustable longitudinal register device.
1.5 The frequency control of motor speed adapts to different printing speeds.
1.6 Suitable for printing the packing material as PE and PP plastic bags,glass papers rolling papers,etc.
Main Technical Specification
Model | YT-4600 | YT-4800 |
Max. width of material | 600mm | 800mm |
Max printing width | 560mm | 760mm |
Length of printing product | 191-914mm | 191-914mm |
Diameter of Roll Material | φ450mm | φ450mm |
Printing Speed | 5-50m/min | 5-50m/min |
Thickness of printing Plate | 2.38mm | 2.38mm |
Total power | 8.5kw | 11.2kw |
Overall Dimension | 4300×1700×2500mm | 4300×1900×2500mm |
Weight | 3000kg | 2000kg |
Picture Show
