Home > Products > Solar Power Solution > High Efficiency Solar Home System 150W
High Efficiency Solar Home System 150W
US$ 250 - 719
/ Set
1 Set(Min. Order)
- Xingang
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | EASTWEST | |
| Model Number | SHS-150W | Specification | Normal | |
| Output Voltage (V) | 220 V | |||
| Load Power (W) | 306 Wh | Solar Power (W) | 150 W | |
| Work Time (h) | 12 H |
Product Description
Specifications
Solar Power Home SystemSolar module: 150W
Battery: 24V, 100Ah
Solar charge controller: 24V, 6A
Inverter: 300W
| Item | EW-SHS150W | ||||||
| Solar module | Type | Polycrystalline Silicon | |||||
| Item/Qty. | SPS075 -12M / 2pcs | ||||||
| Maximum power at STC(Pm) | 75 Wp | ||||||
| Optimum operating current(Imp) | 21.6V | ||||||
| Short circuit current(Imp) | 4.87A | ||||||
| Dimensions l×w×h/Weight | 1195mm × 541mm × 28mm / 8kg | ||||||
| Battery | Type | Lead-acid Maintenance-free Rechargeable | |||||
| System Voltage | 24V | ||||||
| Capacity | 100AH/12V, 2pcs | ||||||
| Dimensions l×w×h/Weight | 329mm × 172mm × 229mm / 31kg | ||||||
| Charge Controller | System Voltage | 24V | |||||
| Max. module input short circuit current | 6A | ||||||
| Dimensions l×w×h/Weight | 130mm × 88mm × 39mm / 0.165kg | ||||||
| Inverter | Type | High frequency pure sine wave | |||||
| Item/Qty. | SK300-224 | ||||||
| Continuous Output Power | 300W | ||||||
| Surge Rating | 600W | ||||||
| Output Voltage | 220V / 50Hz | ||||||
| Protection | Overload, Short circuit, Reverse polarity(FUSE) , Over/under input voltage, Over temperature. | ||||||
| Dimensions l×w×h/Weight | 224mm × 164mm × 78mm / 1.8kg | ||||||
| Control Box | Material | Steel box of zinc-plated and lacquer-coated | |||||
| Color | Gray | ||||||
| Dimensions l×w×h/Weight | 560mm × 550mm × 600mm / 23kg | ||||||
| Capacity of Load: | Load | specification | Load power | number | Working hours/day | Expend/day | |
| Saving light | 11W | 1 | 6 | 66Wh | |||
| Television | 21inch | 70W | 1 | 2 | 140Wh | ||
| Television receiver | 25W | 1 | 4 | 100Wh | |||
| Total | 106W | 306Wh | |||||
