Anon Grain Milling Grain Miller Grain Milling Equipment

Specifications

Anon grain milling grain miller grain milling equipment

Specifications of 20-30TPD rice mill:

1.  Model:20-30T   grain milling equipment

2. Output of white rice: 20-30ton/day (24hours).

3.Total Power of standard equitpment: 37.6kw (no polisher,no color sorter,no electric scale).

4.size of standard dimension: 750x190x372cm.

5. Standard equitpment list: cleaner/husker/paddy separator/rice whitener (no optional items)

6. Voltage: 380V, 50Hz, 3phase. Customed voltage is available, such as 440V or 480V.

7.  Optional item: Polisher/CCD color sorter/electrical scale/Rice storage bin/ Diesel generator etc.

Main Technical Specifications of    grain milling equipment

1.This complete rice millmachine is used to process long rice, is an unconventional plant, can make both white rice and brown rice.

2, Combined cleaner  can remove all the impurities and unfilled grains and stones from raw paddy.

3,Paddy husker shelling to get brown rice.

4,Paddy separator is used to separate the unhusked paddy from brown rice.

5,Rice Whitener can remove the bran layer to get white rice from brown rice.

6, Rice Grader separate the rice into several classes , such as head rice ,big broken ,medium broken ,small broken.

Features of Anon rice mill:

1.    Full automatic compelet production line, with latest technology

2.    Low noise and consumption, compact structure

3.    Easy to operate continuous operation.

4.    High output and low broken rate.

5.    Reasonable price.

6.    Professional Anon work team. Above solution is standard solution according to Chinese paddy features. Anon engineer will change solution to fit client’s local paddy charator and environment. E.g. for Philippine, paddy is wet more than 15% humidity, engineer suggest large capacity of husker series.

Sample Project in Myanmar:   grain milling equipment

 grain milling equipment
