Anping double twisted barbed wire machine(CS-A)
- Xingang port
- T/T
You May Like
Product Details
| Place of Origin | Hubei, China | Brand Name | Sanqiang | |
| Model Number | SQ-M13 | Material | Steel Wire | |
| Surface Treatment | Galvanized |
Product Description
Specifications
barbed wire machine with high qualitymain driving axle rotation speed:132r/min
mainframe:1900x1300x980mm
weight:2t
designed to produce screens with single
double-stranded barbed steel wire,
thermo-plated with zinc
Barbed Wire Machine Barbed Wire Machine is designed to produce screens with single or double-stranded barbed steel wire,thermo-plated with zinc.The machine is of horizontal design,consisting of two parts,assembled together at the middle.It is safe and reliable in operation,capable
of turning out high quality products with consistency.
1,CS-A Double twisted Barbed Wire Machine is designed to produce screens with single or double-strand barbed steel wire,thermo-plated with zinc.The machine is of horizontal design,consisting of two parts,assembled together at the middle.It is safe and reliable in operation,capable of turning out high quality products with consistency.
Item |
|
Motor | 3kw |
Rated output | 70kg/h |
Weight | 1500kg |
Overall Dimension | 1900mmx1300mmx980mm |
Wire collection part size | 1800mmx750mmx750mm |
Barb pitch spacing | 76mm 102mm |
Twist | 4 |
Strand Diameter | 2.2-2.8mm |
Wire Diameter | 1.8-2.2mm |
Rotating Speed of Drive shaft | 432r/min |
2,CS-B single twisted Barbed Wire Machine is designed to produce screens with single or double-stranded barbed steel wire,thermo-plated with zinc.The machine is of horizontal design,consisting of two parts,assembled together at the middle.It is safe and reliable in operation,capable of turning out high quality products with consistency.
Item |
|
Motor | 2.2kw |
Rated output | 50kg/h |
Weight | 1200kg |
Overall Dimension | 1900mmx1300mmx980mm |
Wire collection part size | 1300mmx800mmx700mm |
Barb pitch spacing | As required |
Twist | 4,6 |
Strand Diameter | 1.6-2.6mm |
Wire Diameter | 1.6-2.2mm |
Rotating Speed of Drive shaft | 357r/min |
3, CS-C Barbed Wire Machine for Two-strand Wire with Two-way Twistsis for Two-strand Wire with Two-way Twists can produce the barbed wire with two-way twists.This way is easy to operate and install as they will not entwist with each other.
Item |
|
Motor | 2.2kw |
Rated output | 40kg/h |
Weight | 1200kg |
Overall Dimension | 1900mmx1300mmx980mm |
Wire collection part size | 1300mmx800mmx700mm |
Barb pitch spacing | 76mm 102mm |
Twist | 4 |
Strand Diameter | 2.2-2.8mm |
Wire Diameter | 1.8-2.2mm |
Rotating Speed of Drive shaft | 432r/min |
