Hot Dipped Galvanized Box Trailer
Negotiable
/ Unit
10 Units(Min.Order)
- 500 Unit / Units per Month
- Qingdao China
You May Like
-
2013 heavy duty single/tandem axle utility box/cargo/cage trailer
-
All galvanized chassis cargo trailer
-
All galvanized chassis cargo trailer with galvanized sheet
-
All galvanized chassis folding cargo trailer
-
Heavy Duty Hot-dipped Galvanized Utility Trailer
-
Heavy Duty Hot-dipped Galvanized Utility Trailer
Product Details
| Type | Semi-Trailer | Material | Steel | |
| Certification | CE | Size | 2,100 x 1,200 x 300mm | |
| OEM No. | / | Max Payload | 750KG | |
| Place of Origin | Shandong, China | Brand Name | Rongcheng Longhe | |
| Model Number | / |
Product Description
Specifications
Length: 3.2m/10.5 feet Width: 1.5m/4.9 feet Tire: 155R13 Tail light: LED Hub, rim, axle, leaf spring: hot dipped galvanized· Dimensions: 2,100 x 1,200 x 300mm
· Maximum loading capacity: 750kg
· Surface finish: hot dip galvanized (powder coating is also available)
·Tyre:155R13
•Taillight:LED
· Hub, rim, axle, leaf spring: hot dipped galvanized
·One axle(also we can do two axles)
· Terrain clearance
· Turning radius
•Optional: electric brake
Material | ||||||
| 1.1 GRADE | ||||||
| DuraGal angles,channels and flats are manufactured by a cold forming process which ensures that it complies with the requirements shown below | ||||||
| section | Actual thickness t mm | Grade | Minimum Yield Stress Mpa | Minimum Tensile Strength MPa |
| |
| Flats | t≤6.0 t>6.0 | C400LO C350LO | 400 350 | 450 400 | 20 20 | |
| Angles and Channels | t≤6.0 t>6.0 | C400LO C400LO | 450 400 | 500 450 | 16 16 | |
| DuraGal profiles comply with the requirements of steel type 7B in Talbe 10.4.1 of AS4100. | ||||||
| LO indicates that DuraGal profiles have Charpy V-notch impact properties as specified in TS100[11]. Table 10.4.1 of AS4100 Steel Structures permits impact tested LO grades to have the following minimum servicetemperature: | ||||||
| Actual thickness mm | Lowest one day mean ambient Temperature ºC | |||||
| t≤5 | -30 | |||||
| 5<t≤10 | -20 | |||||
| 1.2 SURFACE FINISH | ||||||
| A minimum of 100g/m² coating of zinc is applied by in-line galvanising to a mechanically(shot blasted)and chemically cleaned bright metal(AS 1627.4 Class 3.0) surface. A clear polymer barrier coating protects the protects the galvanising prior to fabricartion. | ||||||
| 1.3 SIZE RANGE | ||||||
| Equal Angles | Unequal Angles | Channels | Flats | |||
| 30x30 to 150x150 | 75x50 | 75x40 to 300x90 | 50to300 | |||
Craft : blanking,stamping, grilding,welding,assembling,painting, baking etc.
Blanking workshop
surface finishing--- painting finish or baking finish
Fiberglass workshop
Assembly shop
Delivery
Our certification:
Our products & factory:
