19" 3D Holographic Display,3 Direction Display Products

19" 3D Holographic Display,3 direction display products

1. Scope
It usually used at Exhibitions, Trade Shows,Point of Sale including Cars, Watches, Pearls
and Jewels,Shop window,Advertising,Pavilion,Museum,Exhibition/Event,Event,Product
launching
2. Principle
3D holo showcase bases on three-dimension(3D) projection mirror imaging principle,
it can display 3D light and shadow imaging floated in the air under treatment of 3D
imaging device.
Viewers can walk a circle around the four-dimensional imaging system to watch the
mirror image projection
suspended in the air.
3.The machine is composed of 4 parts:
the appearance cabinet, LED display, 3D image transmit device and the display device.
4. Voltage: AC110 - 240V, 12V, 1.5A/3A
5. Video format: Support audio and video formats:MPG,MPG-1,MPG-2,MPG-4,AVI,MP4,DIV,TS,TRP,MKV,WMV,RM,RMVB etc, highest support 1080P(resolution 1920*1080)HD display
6. Memory limit: 16GB, SD/CF card
7. Appearance color: Black or White
8. Input:HDMI/USB
9. remote control:front
10. Resolution: 1280*1024
11. .Material:Sheet metal and toughened glass with rear projection film
12   Warranty
We provide 1 years warranty for hardware and software is free for lifetime.
13. operation:
13.1. Put on the power then it will work.
13.2. Stick the usb or sd card then it can display the video or you can also connect the
showcase with PC by HDMI.
13.3. The remote can adjust the voice and switch the video.and can also set as single
cycle.
13.4. Press the button, then the showcase will turn off.


Screen size:19” LCD color screen (industrial screen)

Diaplay image size:length 400*width 300*height 200(mm)

visual Angle: left and right :270 degree  vertical :160 degree

Display brightness: 400nits(not including led graces)

Color temperature: 9300K(typ)

Screen contrast:  5000:1

Power supply requirement : 110V—240V

Working temperature: -5 to 55℃

Storage temperature: -20 to 70℃

Humidity:(40℃) <95%RH

Half brightness life : 40000 hours

Screen control :remote control

Audio output :8Ω x 5W x2

Display size:length 480* width 380* height 370

1.Metal frame, paint technology, high-end atmosphere.

2.Using AUO 19-inch high-definition screen industry(396.32 (H) x 301.056 (V)),100% full Angle projection without discoloration,seismic resistance, long service life.

3.Main chip MST6M182,this chip including 3D COMB FILTER and 3D Deinterlace,make holographic projection realistic, real to the enemy.

4.With no ghosting HD holographic pyramid, import acrylic material, safe and convenient transportation.

5.Including USB2.0 port,SD card port,CF card port,boot automatically play, support hot plug.

6.Support Chinese, English and other language.

Accessories: extension cord, remote control

Events gifts: 16G sd cards, mass holographic test sources.
