Product Details

Place of Origin	Hubei, China		Brand Name	MJ-QSFP-40G85-1M-xx
Model Number	QSFP-40G85-1M-xx

Product Description

40G-SR4 QSFP+ 850nm 150m Transceiver Module for MMF

Mingjia 40GBASE-SR4 QSFP+ Module supports link lengths of 100m and 150m, respectively, on laser-optimized OM3 and OM4 multimode fibers. It primarily enables high-bandwidth 40G optical links over parallel fiber terminated with MPO/MTP multifiber connectors. It can also be used in a 4x10G mode for interoperability with 10GBASE-SR interfaces up to 100m and 150m on OM3 and OM4 fibers, respectively. The 40Gbps QSFP+ transceiver is well suited for Infiniband and 40GBASE-SR4 applications. It combines the higher density attractions of parallel modules with some of the key advantages normally associated with SFP+ based modules. It is intended for use short reach applications in switches, routers and data center equipment where it provides higher density and lower cost when compared with standard SFP+ modules.

Key Features

QSFP+ MSA, SFF-8436 compatibleOptical connectivity via industry standard MPO/MTP terminated fiber ribbonUp to 100m on OM3 and 150m on OM4 MMFVCSEL array transmitter and PIN array receiver4-lanes, 850nm wavelength independently addressable transmit and receive channels, operates at 10.3125Gbps per channelHighly compact: savings of 60% on edge and board usage compared to four comparable SFP+ modulesElectrically hot-pluggableOperating Case Temperature: 0℃~+70℃Single 3.3V Power Supply and Power dissipation < 1.5WDigital Diagnostics Monitoring Interface

Applications

High-speed interconnects within and between switches, routers and transport equipmentServer-Server Clusters, Super-computing interconnectionsProprietary backplanesInterconnects rack-to-rack, shelf-to-shelf, board-to-board, board-to-optical backplane10GBASE-SR applications40GBASE-SR4 applicationsInfiniBand SDR, DDR and QDR applications

QSFP+ Interface
