Home > Products > Roof and wall panel roll forming machine > siding panel machinery side roll forming machine
siding panel machinery side roll forming machine
- 1 Set / Sets per Month
- Tianjin
You May Like
-
china stud track galvanized strip profile cold roll forming machine
-
TY cold roll light steel keel making machine
-
economic factory light steel keel form machine
-
Cangzhou TY automatic steel keel profile production line
-
economic light steel keel frame machine for ceiling
-
TY beautiful more type keel production line
Product Details
Condition | New | Type | Other, Tile Forming and Cutting Machine | |
Tile Type | Steel | Use | Roof | |
Production Capacity | 12~15m/min | Place of Origin | Hebei, China | |
Brand Name | Tianyu | Model Number | Keel | |
Power(W) | 3Kw+4Kw | Voltage | 380V,50Hz,3Phases | |
Dimension(L*W*H) | 6800*1500*1200 | Weight | 3.6T | |
Certification | CE,BV | Warranty | 12 months | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
siding panel machinery side roll forming machine
This kind of cold roll forming machine is widely used for making various metal wall panels and roof panels for steel constructions, steel structure projects and containment systems etc.
What is the production process of the machine?
uncoiler→Flating→Feeding→Forming→Cut to length→Colletion(finish goods) |
What is the specifications ?(all the details can be made according to your requirments)
Large frame | 300H steel |
Rolling wheel | Forging 45# steel |
Roller station | about 13rows |
Rolling speed | 10-12m/min |
Rolling thickness | 0.2-0.8mm |
Kind of drive | Driving with 1.3 inches chain |
thickness of side-wall | 14mm |
Type of cutting | hydraulic cutting |
Type of forming machine | single layer |
blade material | Cr12 |
What is the main accessorise?
- Tighten to container with steel wire rope and welded machine with container by angel iron.
- Main forming machine and un-coiler is naked(If you need we can also packed with water-proof plastic).
- PLC control system and motor pump are packed with water proof paper coverage.
- We will try our best to keep it intact when you see the machine.
Why choose us?
- Factory ,Quality ,Price and Stock make us better than others.
- The of thickness of our wheel chroming is 5mm. Inferior wheel chroming of the machine is 3mm or less.
- The length of our chain is 1.3 inches(33mm).Inferior chain length is about 0.75 inch(19mm).
- The thickness of our side-wall is at least 14mm. Inferior is only 12mm or less.
- Our company has transducer to control the speed of the machine. Inferior machine does not have transducer to control the speed.
- Details determine success or failure.
- Equipment can be specially designed and manufactured at customers ' requirements.
- Products warranty:12 months. We will provide the technical support for the whole life of the equipment.
&
- Over 18 years experience ,the quality can guarantee .
- We are the professional manufacture to produce different kinds of roll forming machine.
- Maybe our package is not the best. Maybe our delivery time is not the best. But our quality is the best. Good quality which can let machine going well longer is saving money and saving manpower cost .
- So our machine is your best choise.
Send your Inquiry Details in the Below and Click “Send” now.
Q:Are you a manufactuer or trading company?
A:We are a manufacturer specialized in producing all kinds of roll forming machines.
Q:Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world.
Q:What is the payment terms?
A:T/T (30% by TT in advance, the rest 70% to be payed by TT after you inspect the machine in sell s factory before delivery)and T/C.
Q: What can you do if the machine broken?
A: Our machine's quality is very good. And we supply the technical support for the whole life. Because the warranty is one year, if the broken parts can't repair, we will send you the new parts freely. But you need pay the express cost yourself. Thanks for your understanding. If after the warranty period, we can solve the problems through negotiation.
Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. The core of our company culture is honesty and credit. TY is ALIBAB’s Gold supplier with
BV assessment and CE certificate.
Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers’ specifications, using top brand name components.
Q: How does your factory do regarding quality control?
A: Quality is priority. TY People always attach great importance to qulity control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it’s packed for shipment. Be reassured please.
Q: Can you be responsible for transport?
A: Yes. Please tell me the destination port or address. We have rich experience in transport.
Q: Can you supply the raw materials?
A: Yes. We can supply the color steel coil, galvanized steel coil, galvalume steel coil and aluminum coil.
