Product Details
| Condition | New | Application | Dry mortar production line | |
| Production Capacity | 1000kg/batch | Place of Origin | Jiangsu, China | |
| Brand Name | HUQIN | Model Number | LDH-2 | |
| Power(W) | 15kw | Dimension(L*W*H) | 23*20*16m | |
| Weight | 2000-4000kg | Features | High efficiency colter mixer | |
| Warranty | 12 month |
Product Description
Dry Mortar Production Line Quality Products LDH Series Plough Mixer Machine
LDH Series High Efficiency Colter Mixer is widely used for mixing of powdered, granular, flaky, blocky, irregular and sticky materials in feed, food, chemical, pharmaceuticals, pesticide and many other industries. It is especially suitable for the mixture of viscous or rubbery additives.
Plough or sloping blades are set on single shaft. When plough mixer is on operation, special structure leads the material to be continuously mixed. With radial and longitudinal movement simultaneously, dead corner is avoided and thus high accuracy mixing is achieved.
Features:
1.An ideal mixing equipment with high efficiency and high quality features.
2.High mixing uniformity and no mixing blind angle.
3.Fast and quick mixing speed.
4.Good wear resistance and long service life.
5.Unloading fast, no residue.
6.Stable property, low noise, environmental protection.
Technical parameters:
| Model | Effective Volume (m³) | Capacity (kg/batch) | Mixing Time (min) | Power (kw) |
| LDH-1 | 1 | 500 | 3-6 | 7.5 |
| LDH-2 | 2 | 1000 | 3-6 | 15 |
| LDH-4 | 4 | 3000 | 3-6 | 30 |
| LDH-6 | 6 | 5000 | 3-6 | 37 |
| LDH-10 | 10 | 8000 | 3-6 | 55 |
The whole process of dry mortar production line can be divided into following eight processes.
1.Wet Sand Drying System → 2.Raw Materials Storage System → 3.Lifting & Conveying System → 4.Weighing System
→ 5.Mixing System → 6.Packing System → 7.Dust Collector System → 8.Electric Control System
We can manufacture the other related machines or the whole set production line for you based on your requirements.
We have won many honors, such as "National Reputation Tracking Product Quality Services and Outstanding Enterprises", "National Product Quality, Service Quality without Complaint, User Satisfaction Brand Honor", "National Product Quality Surveillance Spot-checks the qualified enterprise" and etc in the past many years. Besides, we have also passed the ISO9001 quality management system certification.
If you have interest in our products, welcome to contact us for future business relationships and mutual success!
