Non Pressure CE Certified Water Heater Solar Collector
- Shanghai/Ningbo
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | INLIGHT | |
| Model Number | INLIGHT-VC | Type | Vacuum Solar Collector | |
| Application | Other, Solar Thermal, project solar water heating | Pipe Material | Glass |
Product Description
Specifications
Water Heater Solar Collector1.OEM avalliable,CE certified
2.Economical collector
3.for large quantity solar heating system
Water Heater Solar Collector Technical Parameters
Vacuum tube | Spec.(mm) | Φ47×1500 Φ58×1800 |
Tube (pcs) | 40 / 50 / 60 / 70 | |
Material | 3.3 Borosilicate glass, magnetron spluttering coating | |
Coating | AL/AL-ALN(H)/AL-ALN(L)/ALN or Cu/SS-ALN(H)/SS-ALN(L)/ALN | |
Manifold | Dimension | 180*160mm, 1.0 inch inlet & outlet |
Inner tank | Food-grade SUS304-2B stainless steel | |
Tank shell | Imported color steel / Fluorocarbon (PVDF) plate | |
Insulation | High-density polyurethane integrated foam-forming layer | |
Bracket | Hot-dip galvanized steel plate (powder coating or paint baking) | |
Accessories | Stainless bolts & nuts, waterproof silicon rubber seal, dustproof rubber seal, plastic tube holder | |
Working pressure | ≤ 1 bar | |
Tilt angle | 0~ 90° | |
Hail resistance | Φ25mm diameter | |
Features description:
The Water Heater Solar Collector (nonpressurized) consists of glass vacuum tube, nonpressurized manifold and supporting bracket, working principle is thermosyphon the same as integrated non-pressurized system, water is heated directly in glass tubes, taking advantage of the natural circulation due to smaller density in hot water than cold water. series or/and parallel arrays of solar collector is usually adopted for large-scale hot water heating project.
1. Especially designed for large-scale hot water heating system, supplying hot water for dormitories, hotels, restaurants, schools, hospitals, factories, swimming pools, and some other sites requiring hot water use or house heating.
2. All-glass vacuum tube, most economical and good performance at the same time
3. Processed color steel shell and galvanized bracket make it a long lifespan as vacuum tubes
4. Easy installation and connection and little maintenance needed
Warranty: 3 years international responsibility for integrated collector exchange and 15 years for glass vacuum tube compensation due to original quality problems
